Формовочная машина для выдувания пластиковых бутылок
US $20000-$50000
Фабричная полностью автоматическая машина для выдувания ПЭТ бутылок с сертификатом
- Категория: Stretch Blow Moulding Machines >>>
- Поставщик: Taizhou,Huangyan,Yuanda,Machinery,Manufacture,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 29155.28 $* | 30613.11 $* |
| Aug-19-2025 | 28910.54 $* | 30356.26 $* |
| Jul-19-2025 | 24255.96 $* | 25468.29 $* |
| Jun-19-2025 | 28420.80 $* | 29841.78 $* |
| May-19-2025 | 24745.73 $* | 25982.10 $* |
| Apr-19-2025 | 27930.60 $* | 29327.36 $* |
| Mar-19-2025 | 27685.89 $* | 29069.13 $* |
| Feb-19-2025 | 27440.23 $* | 28812.39 $* |
| Jan-19-2025 | 27195.83 $* | 28555.32 $* |
Характеристики
Product Description
| ITEM | YD-1800 | YD-3500 | YD-5500 | YD-8000 |
| Theoretical output | 2000 | 4000 | 6000 | 8000 |
| Max.container volume | 2L | 2L | 2L | 2L |
| Max.neck diameter | 38MM | 38MM | 38MM | 38MM |
| Max.container diameter | 120MM | 120MM | 120MM | 120MM |
| Max.container height | 335MM | 320MM | 250MM | 250MM |
| Number of cavity | 2 | 4 | 6 | 8 |
| Number of lamp | 24 | 24 | 24 | 48 |
| Max.heating power | 50KW | 84KW | 90KW | 90KW |
| Installation power | 110KW | 95KW | 100KW | 100KW |
| Actual power consumption | 45KW | 40KW | 50KW | 50KW |
| Operatating low pressure | 0.7-1.0Mpa | 0.7-1.0Mpa | 0.8-1.0Mpa | 0.8-1.0Mpa |
| Low pressure consuming | 2000L/min | 2000L/min | 2000L/min | 2000L/min |
| Blowing pressure | 2.5-3.5Mpa | 2.5-3.5Mpa | 2.5-3.5Mpa | 2.5-3.5Mpa |
| High pressure consuming | 5500L/min | 5000L/min | 2.8~3.5m3/min | 3.5~5.0m3/min |
| Operating pressure | 0.3-0.5Mpa | 0.3-0.5Mpa | 0.3-0.5Mpa | 0.3-0.5Mpa |
| Temperatuer | 10 degree | 10 degree | -10°C~55°C | -10°C~55°C |
| Flow rater | 40 L/min | 40 L/min | 50L/min | 70L/min |
| Machine dimension | 2.25×1.5×2.2 | 3.55×1.5×2.2 | 4.25×1.5×2.2 | 4.5×2.25×2.2 |
| Machine weight | 4200Kg | 4800Kg | 5000Kg | 5000Kg |
