IC circuit precision control, automatic overload protection system adopting digital switch, 1/100 precision re-set control adjustable horizontal level, easy control welding horn high O transducer, optimized output and reliable performance Have resonant frequency when the load, unload, without adjustment for the frequency of welding horn Square column and column airframe structure is optional, the straight line guide bearing, the precise matching device Using the turbine rotation to adjust the machine movement, which is better than normal Adopting Japan HuangPai brand alloy steel to keep frequency strong and stable Celebrate itself durability for adopting USA aviation standard 7075¡¢6064 Aluminum alloy the electronic components are imported from Italy, Japan, American, South Korean, Taiwan and etc all in one high capacity machine, applied for high precision of welding work piece Automatic protective device, which is optional high-power machine, which is applied for Large work piece
Mainly parameter
Model
KLC-2615
KLC-3215
KLC-4215
Input power
2600w
3200W
4200W
Frequency
20KHZ
Input voltage
220V
Max input power
1.2KW
1.9KW
2.3KW
Active horn
70mm
Oscillation system
Auto-stimulating
Output time
0.01-99S
Pressure
Pressure bound 1-7bar
Welding area
200mm
220mm
250mm
Compressor
1HP
Net weight
110kg
100kg
115kg
MFR: KEEPLEADER™ have modified and designed model for our customers’ unique and special requirements, please contact KEEPLEADER™ for updated details
After purchasing at KEEPLEADER™ is first step of our after-service, all of machines at KEEPLEADER™ has one year guarantee, we provide free samples for defected parts to do replacement except for human damage, under information for your notice
01: KEEPLEADER™ always posts the new technical file in our homepage that can help our client in new technical information of machines’ design, character, application, operation, maintenance,
and related, KEEPLEADER™ also welcome our clients feed back the machines’ working condition that can get one to one service
02: If the machine you purchased has any defects, please contact sales representative at KEEPLEADER™, we will assign our experienced engineer analyze your case and provide technical support, in case of damaged parts that cannot repair, KEEPLEADER™ will provide a new parts to replace the defect
03: For any replacement and maintenance, KEEPLEADER™ has user manual and training video
04: KEEPLEADER™ can go to oversea for on-site training
05: KEEPLEADER™ can provide electric diagram if in need
