Shotcrete Machine
Хорошая производительность sizzix big shot machine crete 7 М3 от китайских

Хорошая производительность sizzix big shot machine crete 7 М3 от китайских

Категория: Shotcrete Machine >>>
Поставщик: Henan,Yugong,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.8 $*	0.19 $*
Aug-19-2025	0.3 $*	0.90 $*
Jul-19-2025	0.58 $*	0.55 $*
Jun-19-2025	0.51 $*	0.87 $*
May-19-2025	0.50 $*	0.62 $*
Apr-19-2025	0.35 $*	0.43 $*
Mar-19-2025	0.82 $*	0.99 $*
Feb-19-2025	0.88 $*	0.95 $*
Jan-19-2025	0.78 $*	0.80 $*

Характеристики

Product Description

sizzix big shot machine

YGM series wet concrete shotcrete machine is the ideal equipment for concrete anchor shotcrete construction

Shotcrete Machine

Features and applications

YGM series wet concrete shotcrete machine is the ideal equipment for concrete anchor shotcrete construction.It is widely applicable in

l tunnels,

l underground engineering,

l coal mining, mine shaft,

l water conservancy

l power engineering

l slope protection,

l soil nail wall project and

l anchor shotcrete support construction.

The accelerated agent conveying is an independent system, which accurately controls and adjusts freely through the standard metering pump. The swirler upper shell sets special rubber chamber, which is benefit for mixture conveying through air pressure vibration with non-stick material and smooth internal wall. The machine has advantages of stable performance, easy operation and maintenance, energy saving, long service life, environment friendly to improve shotcrete layer quality.

Specification

(Dry shotcrete machine)

1	Model	YGM-DS5P	YGM-DS7P
2	Capacity (cubic m/h)	5	7
3	Tube Diameter (mm)	51	57
4	Discharge Head (Horizontal)	200m	200m
5	Max Aggregate (mm)	20	20
6	Compressed Air Consumption	10-15m³/min	10-15m³/min
7	Air Pressure (mpa)	0.4-0.6	0.6-0.8
8	Motor Power(kw)	5.5	7.5
9	Rotor Diameter (mm)	438	480
10	Weight (kg)	850	950

(Wet shotcrete machine)

1	Model	YGM-WS5P	YGM-WS7P
2	Capacity (cubic m/h)	5	7
3	Tube Diameter (mm)	51	57
4	Discharge Head	50m(Horizontal) 20m (Vertical)	50m(Horizontal) 20m (Vertical)
5	Max Aggregate (mm)	15	15
6	Compressed Air Consumption	7-10m³/min	7-10m³/min
7	Air Pressure (mpa)	0.2-0.6	0.2-0.6
8	Motor Power(kw)	5.5	7.5
9	Hopper Feeding Height (mm)	1000	1250
10	Weight (kg)	720	830
11	Dimension(mm)	13507501150	14007501300

Package and shipment

Put the spare and vulnerable parts into the carton box

Wooden case fumigation free package or international export wooden case package

Payment

We normally accept T/T in advance, L/C at sight, Ali Escrow, Paypal, West-union

Service

24 Hours online service is available, and local distributors are also available for site support.

Shipment

We supply Door to Door shipment service.

Packaging & Shipping

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Package and shipment

Put the spare and vulnerable parts into the carton box

Wooden case fumigation free package or international export wooden case package
