cheap  Multifunctional small manual round pill making machine  tablet pill press making Mini Herbal Pill Maker Making Machine



whatsapp/wechat:+86 15093228930





1.Brief Introduction



Multifunctional small semi-automatic pill making machine ,small size, low energy consumption, high efficiency, small noise, no pollution, simple operation, safe and reliable, can make water pills, paste pills, and can finish polishing, coating, drying and other operations. Multifunctional small semi-automatic pill making machine, greatly reducing the machine's cumbersome operation procedures, improve efficiency nearly a times, put on the market to supply. Applicable to clinics, small research institutes, large and medium-sized pharmaceutical production laboratories, TCM drug research units, hospitals, Chinese Medicine Shop (room), tonic sales outlets counter-site plus food processing pill-shaped food development.



2.  advantages





3. parameters



MODEL	JC-88A	JC-88B
Round pill diameter	3-12mm	3-23mm
Capacity	2-5kg/h	10-15kg/h
Power	0.28kw	0.54kw
Voltage	220v/110v (customized)	220v/110v (customized)
Dimension	625*210*330mm	660*350*350mm
Weight	25kg	40kg



4. Features



 small manual round pill Traditional Chinese medicine pill making machine can produce honey pill, concentrated pill, water honey pill, water pill, pill-like food, also can coating and drying. Structure: composed of pressure-out strip, clutch roller, pill roller, gear variable speed and electric heating component. the rollers has especially long life span .



5. pictures

6 using method

1. Turn on the power, switch on, and run the machine for a few minutes.

2. The uniform spices will be allocated, the appropriate amount of input into the squeeze groove, the cake, and then the cake-like spices into the groove into strips.

3. Pill-making method: first handle with the hand downward pressure, and then put the bar into the pill groove, and then release the handle, wait a moment after the drug into the pill, immediately put the handle downward pressure, the finished pill is rolled out from the pill tank.

4. Drying method: After the pill is made, the pill is put into the coating device for electrical heating can also be dried, or according to the drug shade or drying.

5. Polishing method: The pill is put into the coating drum roller , continuous tumbling, the longer the rolling time, the surface smoother.
