Экономичная машина для нанесения этикеток на стеклянные
- Категория: Labeling Machines >>>
- Поставщик: Ruian,Furis,Import,&,Export,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 50932.81 $* | 53479.87 $* |
| Aug-16-2025 | 50504.51 $* | 53029.66 $* |
| Jul-16-2025 | 42372.6 $* | 44491.12 $* |
| Jun-16-2025 | 49648.24 $* | 52130.21 $* |
| May-16-2025 | 43228.90 $* | 45389.32 $* |
| Apr-16-2025 | 48792.98 $* | 51232.39 $* |
| Mar-16-2025 | 48364.78 $* | 50782.31 $* |
| Feb-16-2025 | 47936.26 $* | 50333.79 $* |
| Jan-16-2025 | 47508.34 $* | 49883.26 $* |
Характеристики
Application:
FRS-SMA Single label multi-surface labeling machine is our upgraded product, with high adaptability. It can label one side, two sides, three sides and four sides of square bottle,round bottle with single label.
Features:
·The whole machine adopts a mature technology PLC control system, and touch screen,the operation of the machine is stable and high speed
·Upgraded dished label station design, can label conical bottle
·Screw adjustment suppressing mechanism, the movement is accurate
·Synchronization chain mechanism to ensure smooth and precise calibration
·Labeling transparent label without bubble, labeling adhesive sticker does not wrinkle
Device Advantage:
The machine has advanced functions, simple operation and compact structure. Adopt American imported PLC control,24-color true color Taiwan Delta touch-screen operation,Korea photo photoelectric detecting device,combining with imported servo system perfectly, labeling accurately and stably. The speed of Conveyor belt, righting belt, ordering bottles belt are controlled variably. It has the function of no objects no labeling, automatic alarming without labeling.
Technical Parameter:
Model | FRS-SMA |
Driving Mode | Servo control system |
Operating direction | Left or Right |
Production(bottle/min) | 50-100 |
Labeling Speed(m/min) | ≤40 |
Labeling Accuracy | ±1.0 mm(subject to the roughness of the plane) |
The specification of label | Not transparent ,we also can change the machine to use transparent label |
Label roll core | 76 mm |
Label roll diameter | 350 mm (max) |
The size of label | Width 15-150 mm length 15-300 mm |
The diameter of bottle | Max 82.6mm(standard machine) |
Power | 800W |
Voltage | AC220V 50/60HZ Single side |
Machine weight | 500kg |
Machine demisions | 2400*1350*1500mm |
Configuration:
Name | Model | Amount | Remarks |
PLC control system | NX7S-14ADT | 1 Set | America AB |
Touch-screen | DOP-A | 1 Piece | Taiwan Delta |
Inverter | 22F-A2P5N103 | 1 Piece | America AB |
The sensor to test bottle | BF3RX | 1 Piece | Korea Autonics |
The sensor to test non-transparent labels | GS61 | 1 Set | German Leuze |
The sensor to test transparent labels | GSU14B/66.3-S12 | 1 set | German Leuze electronic |
Main transport motor | 180W1:30 | 1 set | German Siemens |
Out label servo motor | 2004-RZ08BAIAN3 | 1 set | America AB |
Driving | QHB88 | 1 set | America AB |
Bottle unscramble motor | 40W1:30 | 1 set | German Leuze |
Separating bottle Motor | 15W1:30 | 1 set | German Leuze |
Transformer | BK100 model | 1 piece | Shanghai |
