Формовочная машина для выдувания пластиковых бутылок
US $20000-$50000
Автоматическая машина для выдувания бутылок горячего
- Категория: Stretch Blow Moulding Machines >>>
- Поставщик: Taizhou,Huangyan,Yuanda,Machinery,Manufacture,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 55930.24 $* | 58727.55 $* |
| Aug-19-2025 | 55460.23 $* | 58233.2 $* |
| Jul-19-2025 | 46530.21 $* | 48857.86 $* |
| Jun-19-2025 | 54520.68 $* | 57246.97 $* |
| May-19-2025 | 47470.50 $* | 49844.96 $* |
| Apr-19-2025 | 53580.4 $* | 56259.65 $* |
| Mar-19-2025 | 53110.1 $* | 55766.12 $* |
| Feb-19-2025 | 52640.56 $* | 55272.46 $* |
| Jan-19-2025 | 52170.72 $* | 54779.33 $* |
Характеристики
Product Description
| General Information | YD-5500-B |
| Clamping Force | 60T |
| Clamping Stroke | 125mm |
| Max.Stretching Stroke | 400mm |
| Bottom Moving Stroke | 0-50mm |
| Cavity No. | 6cavity |
| Output | 2200-4000BPH |
| Space Between Tie Bars | 100mm |
| Max.Mould Thickness | 300mm |
| Voltage Standard | 380V/50Hz |
| Heating Zone No. | 4sections |
| Total Power | 60Kw |
| Max.Bottle Volume | 1.5L |
| Neck Diameter Range | 16-38mm |
| Max.Bottle Diameter | 115mm |
| Max.Bottle Height | 360mm |
| High Pressure System | 3.0-4.0Mpa |
| Low Pressure System | 0.8-1.0Mpa |
| Machine Size | 550x160x200cm |
| Auto-loader Size | 110x120x220cm |
| Net Weight | 4.8T |
Company Information
Factory Picture
Factory Introduction
Yuanda is a focus enterprise ,professional produce blow molding machine, we mainly produce kinds of two-step automatic blow molding machine , semi automatic blow molding machine and cap making machine, we also produce preform mould ,bottle mould and cap mould .
We have advanced technology ,equipment and experience ,spcially in the area of hot filling bottle.Our factory located in Huangyan ,the centre of plastic and mould of china. We have 4 production workshops and more than 20 engineers who can supply perfect service in mould ,machine and technology areas.
We will do our best to satisfy our customers and you are always welcome.
Our Market
| Main Market | Total Revenue(%) |
| Domestic Market | 54.80% |
| Africa | 13.27% |
| Eastern Europe | 12.70% |
| Southeast Asia | 12.53% |
| Mid East | 2.67% |
| South Asia | 2.19% |
| South America | 1.32% |
| Central America | 0.52% |
Our Certification
FAQ
Q: Are you a factory or trading company?
A: We are factory.
Q: How long the warranty period?
A: All of products have one year warranty.
Q: What is your delivery time and payment term?
A: About 30 days after payment ,the payment term is 30% as deposit and 70% should pay before shipment.
Q: How about the quality of machine?
A: Yuanda have been focusing on quality issues,quality control from beginning to the end ,and we will test machine strictly before packing and delivery.
Q: Can we visit your factory?
A: Yes, you are welcome to visit our factory.
Q: Where is your factory located,how do we get there?
A: We are in NO.32 huachang road shidaren industry zone,Huangyan district,Taizhou city, Zhejiang province,China.
You can by air to Luqiao airport and then we will go to pick you.
Our Service
1) Pre-sale Service
Inquiry and consulting support
Sample testing support
View our factory
2) After-sale Service
Free charge for mould design
Training how to instal and use the machine
Engineers available to install and test machine overseas
1 year warranty and lifetime maintenance
Production Flow
Auxiliary Machines
1. High pressure air compressor
| Model no. | Air discharge (m³/min) | Dischaege pressure (Mpa) | Motor power (kw) | Weight (kg) | Size(L*W*H)MM |
| 09wm | 2.4 | 3.0 | 11*2 | 1090 | 1900*1700*950 |
2.Low pressure air compressor
| Model no. | Air discharge (m³min) | Discharge pressure (Mpa) | Motor power (kw) | Weight (Kg) | Size(L*W*H)MM |
| 09w-1.6/10 | 1.6 | 1.0 | 15 | 680 | 1800*860*1600 |
3.Air tank
| Model no. | Max temperature | Pressures (Mpa) | Volume (m³) | Weigh (kg) | Size(L*W*H)MM |
| 11-2839 | 150 | 3.2 | 0.6 | 260 | 1050*650*1100 |
4.Air cooling dryer
| Model no. | Capacity (m³) | Pressure (Mpa) | Temperaure (°C) | Weight (kg) | Size(L*W*H)MM |
| 3-3 | 3.0 | 3.2 | 2-10°C | 150 | 1200*700*1250 |
5.Mould chiller
| Model no. | Max film | Compressure (HP) | Water tank (L) | Weight (kg) | Refrigerant | Size(L*W*H)MM |
| JCWC-5HP | 120L/min | 5 | 55 | 60 | R22 | 960*650*1000 |
6. Air filter
| Model no. | Capacity (m³) | Pressure (Mpa) | Temperature (°C) | Weight (kg) | Size(L*W*H)MM |
| 3.0 | 3.2 | 1-100°C | 20 | 30*30*60 |
Packaging & Shipping
We usually pack the machines in wooden cases according to international standards.
Contact us
TAIZHOU HUANGYAN YUANDA MACHINERY MANUFACTURE CO., LTD
Sen Wang
Address : NO.32 HUACHANG ROAD SHIDAREN INDUSTRY ZONE ,HUANGYAN DISTRICT,TAIZHOU CITY , ZHEJIANG PROVINCE 318020 P.R.CHINA
