New 5 sided pad heating technology and aluminum shelves with excellent temperature uniformity and faster heating rates
Summary:
vacauum oven is designed specially for drying of meterial which is thermo-sensitive or decompouded and oxidative easily .it can be filled with inert gases.which is especially for a rapid dring of some compoud material.
Features:
1. The rectangular working room makes full use of effective volume. Microcomputer control instrument with functions of high precision on temperature control
2. Double-layer tempering bulletproof glass door is easy to observe the articles in the working room. it can be filled with inert gases
3. The closed door could be adjusted. The complete formed high temperature resistance silicon rubber door-sealing ring could guarantee the high vacuum degree.
4. The working room adopts brightpolished stainless steel or cold-rolled steel plate. It is longlife and esay to clean
5.Store,heating,experiment and drying can be done with no oxygen or inert gases,it will not lead to oxidation
Specifictions:
Model
JK-VO30
JK-VO50
JK-VO90
JK-VO125
Supply Voltage
110V +/-10% 50/60Hz 220V +/-10% 50/60Hz
Input power
1000W
1400W
1800W
2500W
Temperature
Controller: Microcomputer PID controlled with LCD display Range:RT-200C Display units: Fahrenheit or Celsius Accuracy: +/- 1°C Warm-up time to 100c within 30 minutes
Vacuum
Ultimate vacuum level: better than 500 microns/millitorrs Mechanical gauge range: 0 to 30 inch mercury Vacuum port: KF25 flange x 1 Vent port: 3/8" hose barb
