Горячая Распродажа Электрический сварочный аппарат hdpe по низкой
- Категория: Plastic Welders >>>
- Поставщик: Zhuji,Yuhan,Pipe,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 714.45 $* | 750.59 $* |
| Aug-16-2025 | 708.95 $* | 743.28 $* |
| Jul-16-2025 | 594.83 $* | 624.7 $* |
| Jun-16-2025 | 696.11 $* | 731.48 $* |
| May-16-2025 | 606.62 $* | 636.86 $* |
| Apr-16-2025 | 684.3 $* | 718.76 $* |
| Mar-16-2025 | 678.44 $* | 712.59 $* |
| Feb-16-2025 | 672.61 $* | 706.72 $* |
| Jan-16-2025 | 666.8 $* | 699.35 $* |
Характеристики
Product Description
| hdpe electric fusion welding machine with cheap price | ||
Dimension | L×W×H(mm) | 600mm*325mm*520mm |
Input voltage | Input voltage | 220V±20% or 380V±20% |
Input frequency | 40~65Hz | |
Output power supply | Output voltage | Refer to type definition |
Output power | Refer to type definition | |
Main characteristics | Ambient temperature | -15℃~45℃ |
Storage temperature | -30℃~70℃ | |
Control mode | Constant volt/Constant current/ Constant power | |
Recording number of data | 480 | |
Output stability accuracy | ≤±0.5% | |
Duty cycle | 60% | |
Data output port | Scanner/USB/Printer | |
| Get Latest Price Now | Ask for OEM service |
Type | φ160 | φ200 | φ250 | φ315 | φ450 | φ630 | φ800 | φ1000 | φ1200 |
Materials | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF |
Range of diameter | 63-160 mm | 63-200 mm | 90-250 mm | 90-315 mm | 280-450 mm | 400-630 mm | 630-800 | 710-1000 mm | 800-1200 mm |
Ambient temp. | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ |
Power supply | 220V±10 % | 220V±10 % | 220V±10 % | 220V±10 % | 380V±10% | 380V±10% | 380V±10% | 380V±10% | 380V±10% |
Frequency | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz |
Total power | 2.63 kW | 2.93 kW | 4.05 kW | 4.95 kW | 7.10 kW | 10.5 KW | 18.2 KW | 24 KW | 29.5 KW |
Heating plate | 1.2 kW | 1.5 kW | 2.3 kW | 3.1 kW | 4.5 kW | 7.5 KW | 12.5KW | 17.5KW | 21.5 KW |
Milling cutter | 0.68kW | 0.68kW | 1.0kW | 1.1kW | 1.1kW | 1.5KW | 2.7 KW | 3.5 KW | 5 KW |
Hydraulic unit | 0.75 kW | 0.75 kW | 0.75 kW | 0.75 kW | 1.50 kW | 1.5 KW | 3.0KW | 3.0KW | 3.0KW |
Max. Pressure | 4MPa | 4MPa | 4.5MPa | 5.0MPa | 0-6.3MPa | 0-6.3MPa | 0-10MPa | 0-10MPa | 0-10MPa |
Hydraulic oil | 46# | 46# | 46# | 46# | 46# | 46# | 46# | 46# | 46# |
Max. Temperature of heating plate | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ |
Difference in surface temperature of heating plate | ±3℃ | ±3℃ | ±3℃ | ±3℃ | ±5℃ | ±7℃ | ±10℃ | ±10℃ | ±10℃ |
Packing | 2 Plywood cases | 2 Plywood cases | 2 Plywood cases | 2 Plywood cases | 3 Plywood cases | 3 Plywood cases | 3 Plywood cases | 3 Plywood cases | 3 Plywood cases |
Size | 0.42CBM | 0.45CBM | 0.69CBM | 0.85CBM | 1.96CBM | 3.02CBM | 4.69CBM | 8.5CBM | 10.8CBM |
Total Weight | 119KGS | 122KGS | 146KGS | 202KGS | 456KGS | 590KGS | 1,100KGS | 1,300KGS | 1,600KGS |
Type | φ160 | φ200 | φ160 | φ200 | φ250 | φ250 |
Materials | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF | PE,PP,PVDF |
Range of diameter | 63-160 mm | 63-200 mm | 63-160 mm | 63-200 mm | 90-250 mm | 90-250 mm |
Type | 2 Jaws ,hand push/wheel | 2 Jaws ,hand push/wheel | 4 Jaws ,hand wheel | 4 Jaws ,hand wheel | 2 Jaws ,hand wheel | 4 Jaws ,hand wheel |
Ambient temp. | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ | -5~40℃ |
Power supply | 220V±10 % | 220V±10 % | 220V±10 % | 220V±10 % | 220V±10 % | 220V±10 % |
Frequency | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz |
Total power | 1.88 kw | 2.18 kw | 1.88 kw | 2.18 kw | 2.83kw | 2.83kw |
Max. Temperature of heating plate | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ | 299℃ |
Difference in surface temperature of heating plate | ±3℃ | ±3℃ | ±3℃ | ±3℃ | ±3℃ | ±3℃ |
Packing | 1 Plywood case | 1 Plywood case | 1 Plywood case | 1 Plywood case | 1 Plywood case | 1 Plywood case |
Size | 0.15CBM | 0.2CBM | 0.22CBM | 0.25CBM | 0.25CBM | 0.28 |
Total Weight | Hand push:41KGS Hand wheel:35KGS | Hand push:46KGS Hand wheel:40KGS | 42KGS | 59KGS | 58kgs | 90KGS |
Type | Size | Power | Voltage frequency | Temperature | Packing | Qty in carton | G.W | Carton Size |
Digital display type | 20-32 | 800w | 220V/50HZ | 0-300℃ | metal box+carton | 5 | 14 | 430*190*470 |
20-63 | 1000w | 220V/50HZ | 0-300℃ | metal box+carton | 2 | 17 | 460*260*260 | |
75-110 | 1200w | 220V/50HZ | 0-300℃ | metal box+carton | 5 | 24 | 450*260*470 | |
double temperature control type | 20-63 | 1500w | 220V/50HZ | 0-300℃ | metal box+carton | 5 | 28 | 530*300*520 |
75-110 | 1800w | 220V/50HZ | 0-300℃ | metal box+carton | 5 | 28 | 530*300*465 | |
Y-type | 16-32 | 1200w | 220V/50HZ | 0-300℃ | metal box+carton | 10 | 26.5 | 470*380*380 |
20-40 | 800w | 220V/50HZ | 0-300℃ | metal box+carton | 10 | 21.5 | 470*380*380 | |
Thermostat type | 20-32 | 600w | 220V/50HZ | 0-300℃ | plastic box+carton | 10 | 16.5 | 535*355*490 |
20-63 | 800w | 220V/50HZ | 0-300℃ | plastic box+carton | 10 | 21 | 535*355*490 | |
75-110 | 1200w | 220V/50HZ | 0-300℃ | metal box+carton | 5 | 21 | 490*280*410 |
Packaging & Shipping
Packaging Details:standard export wooden case
Delivery Detail:Shipped in 15 days after payment
Related Products
Company Information
Zhuji Yuhan Pipe Industry Co.,ltd was founded in 2015.The main products are all related to the plastic pipe welding equipment and plastic pipes,such as hdpe pipe welding machine and electrofusion welding machinesand pe pipes and fittings.We have a professional production. research and development base both in China. Yuhan has won the acceptance of global user, with the excellent quality , practical performance, and perfect after-sales service.Because our faith is one sales with long life service.Incerely wish to cooperate with you.
Our Services
FAQ
1.What is your payment term ?
Sample order . 100% in advance by T / T , Western Union , Paypal or Trade assurance.
Bulk order : T / T , 30% deposit , 70% against copy of B / L.
2. Do you have stock for sample ?
Yes, you can get available samples in our stock. Free for the samples, as long as you afford the express freight cost.
3. How long can I expect to get the sample?
After confirmed orders, the samples will be sent to you via express and arrive in 5-7 days
4. What about the lead time?
Usually within 20 days.
5. Do you have stock for sample ?
Yes, you can get available samples in our stock. Free for the samples, as long as you afford the express freight cost.
