Характеристики




High quality expanded polyethylene eps pre-expander machine

Product Description

 1. The machine includes pre-expander, drying bed, high-pressure feeding fan, screw conveyor, material silo and all other necessary parts.

2. It is controlled by PLC system and it has touch screen which can realize a full automatic cycle operation of material feeding, steam feeding, temperature controlling, foaming and discharging.

3. The material of the pre-expander body is stainless steel.

4. The machine is composed of Chinese famous-brand and high-quality pneumatic elements which can supply a reliable quality and convenient operation to ensure a precise temperature control and uniformity of beading and density.

5. This machine can be matched with drying bed to realize a continuous operation of drying.






 2019-06-11 14.36.40

 2019-06-15 18.19.22

Specification



Items

SPJ1200

SPJ1400

SPJ1500

Chamber

Expander Chamber Diameter

1200mm

1400mm

1500mm

Volume

1.5m3

4.5m3

5m3

Efficient Volume

1m3

3.2m3

3.8m3

Steam

Inlet

50mm

50mm

50mm

Consumption

7-10kg/cycle

15-18kg/cycle

18-20kg/cycle

Pressure

0.6-0.8mpa

0.6-0.8mpa

0.6-0.8mpa

Compressed Air

Inlet

40mm

40mm

40mm

Consumption

0.5-0.6m3/cycle

0.5-0.6m3/cycle

0.5-0.6m3/cycle

Pressure

0.6-0.8mpa

0.6-0.8mpa

0.6-0.8mpa

Drainage

Drainage Outlet

80mm

100mm

100mm

Condensate water Outlet

80mm

80mm

80mm

Electricity

Installed power

16.5kW

23kW

24.15kW

Capacity

12g/l

220-250kg/hour

500-600kg/hour

580-630kg/hour

18g/l

300-320kg/hour

800-900kg/hour

850-950kg/hour

20g/l

400-430kg/hour

1000-1100kg/hour

1100-1200kg/hour

30g/l

550-600kg/hour

1300-1400kg/hour

1400-1500kg/hour

second expansion

no second expansion function

second expansion

second expansion

80-90m3/hour

90-100m3/hour

Density

12-40g/l

6-40g/l

6-40g/l

Overall Dimension

3700x1500x3500mm

3700x3000x5300mm

3700x4150x5400mm

Weight

3500kg

4800kg

5000kg

Workshop Height Required

5000mm

6000mm

6000mm
