Vertical cryogenic liquid tank 99.9% high purity N2O ISO tank china produce 20000L cryogenic liquid tank
Product Details
Scope of supply:
(1)tank body 1 set
(2)The Valves of tank (equipped with high-quality valves, instruments and liquid level gauge listed in the following:
Valves list (get more details on process chart)
|
NO. |
Description |
Code |
Model |
Quantity |
|
1 |
Pressure Building-up Valve |
328DJ25 |
PN4.0 DN25 |
1 |
|
2 |
Upper Liquid Inlet Valve |
328DL40 |
PN4.0 DN40 |
1 |
|
3 |
Lower Liquid Inlet Valve |
328DL40 |
PN4.0 DN40 |
1 |
|
4 |
Liquid Discharge Valve |
328DJ40 |
PN4.0 DN40 |
1 |
|
5 |
Pressure Building-up Adjustable Valve |
253DE20C |
PN2.5 DN20 |
1 |
|
6 |
Three-way Valve |
251DT25A |
PN2.5 DN25 |
1 |
|
7 |
Gas Passing Valve |
328DJ25 |
PN4.0 DN25 |
1 |
|
8 |
Air-Return Valve |
328DJ25 |
PN4.0 DN25 |
1 |
|
9 |
Vent Valve |
328DJ25 |
PN4.0 DN25 |
1 |
|
10 |
Residual Discharge Valve |
251DA8 |
PN4.0 DN8 |
1 |
|
11 |
Safety Valve of Inner Valve |
7K25 |
PN2.5 DN25 |
2 |
|
12 |
Outer Vessel Safety Valve |
H019 |
|
1 |
|
13 |
Piping Safety Valve |
350PSI |
DN8 |
1 |
|
14 |
Fullness Indication Valve |
328DJ10 |
PN4.0 DN10 |
1 |
|
15 |
Control Valve of Liquid Valve |
|
DN4 PN4.0 |
1 |
|
16 |
Vacuum Valve |
ZK-30WA |
|
1 |
|
17 |
Pressure Indication of Inner Vessel |
YO-100 Manometer |
0~2.5MPa |
1 |
|
18 |
Liquid Level Indication |
Differential Pressure Type |
0~15000mm |
1 |
Technical documents 1 set
Including:
Safety Performance Inspection Certificate of Pressure Vessel Product one copy
Quality Certificate of Pressure Vessel one copy
Eligible Certificate of Product one copy
Material List of Main Compressive Elements one copy
All Kinds of Test and Inspection Report one set
Location Diagram of Welding Seam Detection one copy
Nameplate Copy one copy
Eligible Certificate of Complete Valve Instrument one set
Final Drawing two copies
Operational Instruction Manual one copy
Operational Instruction Manual of Liquid Level, Safety Valve one set
| What weight? | Q:What is the weight of gas can fill in cylinder? |
| A: 40L cylinder can fill in 20kg gas,we can recommended the cylinder according to weight of gas. | |
| what pressure? | Q:What is pressure of the cylinder you can provide? |
| A:150bar is most commonly used,we can provide the pressure for 200bar,250bar,300bar and 350bar. | |
| Which valve? | Q:which valve of the cylinder you can provide? |
| A:Different gas and different countries use different cylinders, we can do as your request | |
| Delivery Time? | Q: What is the delivery time of the gas cylinders in DSW? |
| A: 20-25 Days for doing cylinder,7days for gas-filled | |
| how to Packing? | Q: Can you detail about the gas cylinders, packing and shipping? A: Packed by pallets can load 260-280 pieces in one 20ft container |
| Any Protection? | Q: Do you have any protection for the head of the cylinder? A: Yes, in DSW, in each of the cylinders for purity test, purity is not qualified cylinders for processing, no shipment. |
| DSW Advantages? | Q: Why DSW is more worthy of our choice? A:1. Original Manufacturer:DSW has professional equipments for gas cylinders. 2. Large Output capability: DSW has the capability to produce more than 20,000pcs of Gas Cylinders per month. 3. Series: DSW has different series and models for different standards. 4. Exporting experience: We have 20 years' experience for exporting business. |
| Special attention? |
Q: Do you have any special attention about the gas? A: Yes, pay attention to that before use, please open a little bit of the valve and blew the ash off the valve and piping on the grey, because impurities affect the purity of bottle. |
