Гидравлическая буровая установка на глубину 300 м гусеничного типа для бурения водяных
- Категория: Mine Drilling Rig >>>
- Поставщик: Henan,Yugong,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.28 $* | 0.52 $* |
| Aug-15-2025 | 0.71 $* | 0.95 $* |
| Jul-15-2025 | 0.8 $* | 0.34 $* |
| Jun-15-2025 | 0.53 $* | 0.50 $* |
| May-15-2025 | 0.11 $* | 0.91 $* |
| Apr-15-2025 | 0.24 $* | 0.17 $* |
| Mar-15-2025 | 0.49 $* | 0.35 $* |
| Feb-15-2025 | 0.30 $* | 0.10 $* |
| Jan-15-2025 | 0.29 $* | 0.50 $* |
Характеристики
300m Depth Crawler Type Hydraulic Drill Rigs Water Well Drilling Rig Machine For Drill Water Well
Product Description
Introduction about water well rig drilling machine
FY series multi-function hydraulic well drilling truck parallel gear box design, oil pump monomer separation, reasonable power supply and distribution,with power head device, gearbox casting, dual motor power.
At the same time,there are professional excavator chassis,strong and durable,high bearing capacity, small chain plate width,and small damage to the hard surface.
Detailed data about water well rig drilling machine
Model | YG-FY800 | YG-FY600 | YG-FY400 | YG-FY300 |
Drilling diameter (mm) | 140-500 | 140-500 | 140-350 | 140-325 |
Drilling depth(m) | 800 | 600 | 400 | 300 |
One-time advance length(mm) | 6600 | 6600 | 6600 | 6600 |
Walking speed(Km/h) | 2.5 | 2.5 | 2.5 | 2 |
Climbing angles(Max.) | 30 | 30 | 30 | 30 |
Min.ground clearance(mm) | 250 | 250 | 250 | 250 |
Using air pressure(mpa) | 1.7-3.5 | 1.7-3.5 | 1.7-3.5 | 1.7-3.3 |
Air consumption (m3/min) | 17-35 | 17-35 | 17-35 | 23 |
Monitor rate(Kw) | 140 | 115 | 95 | 84 |
Swing speed(rpm) | 55-115 | 45-115 | 45-115 | 55-115 |
Swing torque(N.m) | 8660-11150 | 8500-10050 | 8500-10000 | 7200-9500 |
Dimension(mm) | 6100*2100*2900 | 5400*2100*2850 | 5050*2100*2800 | 4350*1850*2750 |
Weight(T) | 13 | 12 | 10 | 9 |
Company Information
Henan Yugong Machinery Co., Ltd, located in Zhengzhou,Henan province,China.Its a large engineering machinery manufacturing enterprise which focus on research and development, production and sale kinds of drilling rigs.Our drilling rigs are widely applicable for water well, farm irrigation, geological prospecting, small pile foundation, geothermal air-conditioner and so on.
We insist on the strategy of technology research and development. Technical design, material purchasing, precised manufacturing and strict quality inspection are all processed according to the ISO9001 standard. Sincerely hope we can establish close,trustworthy and long term relationship with each customers. Any interests and needs about our Drilling rigs,please contact us.
FAQ
1.Q:How do i know which type of drilling rigs suitable to me?
R:Please inform us your application,drilling objects(Rock/soil/sand etc),drilling depth and drilling diameter,we will recommend the most suitable one for you.
2.Q:What is the MOQ?
R:MOQ is 1 set,we allow OEM and sample order,but the cost are paid by your side.
3.Q: What is the warranty time of your products?
R: The warranty time is 12 months from the date of the commissioning.
4.Q: How does your factory do regarding quality control?
R: All products have to pass strict inspection before they ship out.If you need other certificate and quality control,please contact us.
5.Q: Where is your factory located? How can I visit there?
R: Welcome to visit us!Our factory is located in Zhengzhou City, Henan Province,China.Contact us ahead before you go visit,then we can fully arrange the schedule and meet you.
