DILONG M30 6.6kw ev зарядное устройство

Категория: On Board Chargers >>>
Поставщик: Shijiazhuang,Dilong,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.69 $*	0.14 $*
Aug-19-2025	0.31 $*	0.60 $*
Jul-19-2025	0.92 $*	0.97 $*
Jun-19-2025	0.79 $*	0.3 $*
May-19-2025	0.70 $*	0.28 $*
Apr-19-2025	0.55 $*	0.30 $*
Mar-19-2025	0.41 $*	0.84 $*
Feb-19-2025	0.65 $*	0.98 $*
Jan-19-2025	0.78 $*	0.68 $*

Характеристики

DILONG M30 6.6kw ev charger 150v power charger

Product Description

Specification

Model Specification/unit			DA6K6M30-150C
Mains Input	Rated Voltage	Vac	220 (charger intelligent detection ac input voltage, lower than AC185V, half power output)
	Voltage Range	Vac	85~265
	FREQ RANGE	HZ	47~63
	Efficiency	%	≥95 (Not including auxiliary power supply)
	Power Factor		≥0.99@220Vac,rated power
	Current	A	≤32@220Vac
Mains output	Rated output voltage	Vdc	150
	Max current	A	50@100Vdc
	Constant power output	W	6000
	Constant voltage output range	Vdc	100~200
	Output voltage accuracy	V	≤±1%Vo input 175Vac-265Vac,output 10%-100% load
	Line regulation	%	≤±1Vo input 175Vac-265Vac,output 100% load
	Load regulation	%	≤±1Vo input 220Vac,output 10%-100% load
	Ripple and noise	mV	≤±3%Vo 20M oscilloscope,Twisted-pair cable test.
Auxiliary supply	Rated output voltage	Vdc	12
Auxiliary supply	Rated output power	W	2 (For BMS awakening signal)
Property	Input over-voltage protection	Vac	>275 CAN directive warning protection
	Input under-voltage protection	Vac	<85 CAN directive warning protection
	Output Over-current protection	A	≥110%Io CAN directive warning protection
	Output under-voltage protection	Vdc	< 90 CAN directive warning protection
	Output over-voltage protection	Vdc	>205 CAN directive warning protection
	Over-temperature protection	℃	85±5 CAN directive warning protection
	Output short circuit protection		Yes
	Reverse polarity protection		yes
	Dynamic response	us	≤200
	CAN communication		Communication interrupt, timeout of 20 seconds intelligent shutdown, communication normal recovery.
Work environment	Operating temperature		-40℃~+70℃(Intelligent derating shell temperature above 70 ℃)
	Storage temperature		-45℃~+95℃
	Operating humidity	%RH	20-90(No condensation)
	Storage humidity	%RH	10-95(No condensation)
	Degree of protection		IP66
	Type of cooling		air-Cooling
Safeguard	Isolation Voltage		shell←input→output:2.8KVdc; Main Output→shell:2KVdc; Auxiliary Output→shell:700Vdc
Safeguard	Insulation resistance	MΩ	input—output—shell>10 (25℃,70%RH)
Structure	weight	Kg	12
Structure	Dimensions	mm	316301133
