Ddgt 350KV генератор ndt ультразвуковые XXG-3505 рентгеновской дефектоскопа трубопровода сварочная проверка оборудования керамической плитки для использования в медицине
- Категория: Other Test Instruments >>>
- Поставщик: Dandong,Flaw,Detector,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 11067.93 $* | 11620.28 $* |
| Aug-18-2025 | 10974.18 $* | 11523.28 $* |
| Jul-18-2025 | 9207.60 $* | 9667.24 $* |
| Jun-18-2025 | 10788.21 $* | 11327.21 $* |
| May-18-2025 | 9393.23 $* | 9863.85 $* |
| Apr-18-2025 | 10602.75 $* | 11132.6 $* |
| Mar-18-2025 | 10509.98 $* | 11034.31 $* |
| Feb-18-2025 | 10416.58 $* | 10937.78 $* |
| Jan-18-2025 | 10323.90 $* | 10839.9 $* |
Характеристики
Our Company
Product Description
Product Application
Portable X-ray Flaw Detector are widely used in the defense industry, boiler, pressure vessel, shipbuilding, papermaking, petrochemical, aerospace and industrial machinery and etc, it is the most ideal equipment for nondestructive testing.
Specifications For XXG -3505X Ray Flaw Detector | ||||||
Power supply | AC 198-242V/ 50-60 Hz | Output Voltage | 200-350KV | |||
Power Capacity | 3.5 KW | 2Output Current | 5mA | |||
Fluctuation | ±2% | Focal Spot Size (mm) | 2.5*2.5 | |||
Radiation Coverage | 40° | Max Penetration (Fe) | 60mm | |||
Sensitivity | 1.8% | Size of Controller (mm) | 320*180*350 | |||
Weight of controller (kg) | 13 | Size of generator (mm) | 320*320*660 | |||
Weight of generator (kg) | 41 | Cooling | Air | |||
Cooling | Air | Insulation | SF6 | |||
Working Pressure | 0.34-0.45 Mpa | Working Temp& Humidity | -30-40 ℃, ≤85% | |||
Main Features
1) Factory with 30 years' experience
2) Multi Protection Functions
3) Smaller size, light weight
4) CE marked, ISO Certified
Certifications
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Free Training
* View our Factory.
After-Sales Service
*24 hours online service
* one year warranty
Packing & Delivery
Packaging | ||
Size | 450*450*880mm | |
Weight | 80 Kg | |
Packaging Details | The normal package is wooden bof export to european countries,the wooden box will be fumigated. | |
Packaging | ||
Size | 450*450*880mm | |
Weight | 95 kg | |
Packaging Details | Customized Suitcase, easy for carry. | |
