Горячая Распродажа Супер Бесшумный дизельный генератор мощностью кВт кВА

Genset Specification

Genset Model

HF-120GF

Prime Power(50HZ)

120KW/150KVA

Standby Power(50HZ)

132KW/165KVA

Frequency/Speed

50Hz/1500rpm

Standard Voltage

230V/400V

Overall Dimensions

2400*860*1350 (MM)

Net Weight

980 (KG)

Phases

Three phases, four wires

Engine Specification General Performance

Manufacturer:

Cummins Engine Co., Ltd.

Engine Model:

6BTAA5.9G2

Engine Type:

4 stroke, V-type, 6-cylinder

Engine Speed:

1500 rpm

Prime Power:

120KW

Standby Power:

132KW

Governor Type:

Electric

Air Intake Way:

Turbo charged & intercooled (air to air)

Displacement:

5.9L

Cylinder Bore * Stroke:

102mm × 120mm

Compression Ratio:

15.0:1

Coolant Capacity Engine Only

20 Liters

Alternator data

Engine Model:

Stamford / Godlike

Phase

3 Phase

Power Factor

0.8

Drip Proof

IP 22

Insulation class

H

Voltage regulation

± 0,5 %

Altitude

≤ 1000 m

Over speed

2250 min -1

Generator Standard Configuration

♦ Assembled by Cummins diesel engine and world famous brand alternator

♦ Radiator and fan with safety guard

♦ Automatic control panel and electricity output switch cabinet

♦ Float battery charger and solenoid switch as standard supply scope

♦ Built-in shock pad

♦ Heavy duty steel as base frame and 6-8hrs operation base fuel tank.(suit for 8kva-750kva)

♦ Optional voltage rank: 230V/400V, 220V/380V, 127V/220V, 240V/480V etc.

Our Commitment

♦ Products and services all comply with ISO8528 and GB/T2820 manufacturing standards.

♦ Management is implemented in strict accordance with ISO9001 Quality Management System and ISO14001 Environmental Management System.

♦ All products are CE-certified.

♦ All products have passed rigorous factory test to ensure high quality.

♦ Product warranty terms are strictly enforced.

♦ High-efficiency assembly and production lines ensure on-time delivery.

♦ Regular and irregular technical training are provided all year round.

♦ 24/7/365 Customer Service Center provides fast and effective responses customers

FAQ(Frequently Asked Question):

1.What is your warranty period?

Our warranty period is 1 year or 1000 running hours whichever comes first. But based on some special project, we can extended our warranty period.

2.Does your generator have global warranty?

Yes, most of our products like Cummins, Perkins, Doosan power generator enjoy the global warranty service. And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.

3.Can you accept OEM?

Yes, we can accept OEM.

4.What is your payment terms?

We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.

5.What is your delivery time?

Our normal delivery time is 2 to 5 weeks.
