КВт pwm солнечный инвертор гибридный контроллер солнечного
- Категория: Солнечные инверторы >>>
- Поставщик: Foshan,Top,One,Power,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.11 $* | 0.4 $* |
| Aug-17-2025 | 0.1 $* | 0.17 $* |
| Jul-17-2025 | 0.87 $* | 0.50 $* |
| Jun-17-2025 | 0.30 $* | 0.38 $* |
| May-17-2025 | 0.31 $* | 0.97 $* |
| Apr-17-2025 | 0.6 $* | 0.56 $* |
| Mar-17-2025 | 0.27 $* | 0.60 $* |
| Feb-17-2025 | 0.12 $* | 0.54 $* |
| Jan-17-2025 | 0.89 $* | 0.42 $* |
Характеристики
Products Description
Model | HSI-351 | HSI-501 | HSI-601 | HSI-801 | HSI-102 | HSI-122 | ||||||
Rated power | 350W | 500W | 600W | 800W | 1000W | 1200W | ||||||
Surge power | 1050W | 1500W | 1800W | 2400W | 3000W | 3600W | ||||||
AC Input & Output | ||||||||||||
Voltage | 220VAC | |||||||||||
Selectable Voltage Range | 165-275VAC (220VAC) | |||||||||||
Frequency Range | 50Hz/60Hz automatic recognition | |||||||||||
AC Voltage Regulation (BATT. Mode) | (DC Batt.mode)220vac±3% | |||||||||||
Transfer Time | ≤8ms | |||||||||||
Wave Form | Pure Sine Wave | |||||||||||
Transformer type | Toroidal | |||||||||||
Transfer efficiency | ≥85% | |||||||||||
Battery | ||||||||||||
Battery Voltage | 12V | 12V/24V | ||||||||||
Type | Gel/SLA/AGM/Water battery | |||||||||||
DC Charge Voltage | 13.8VDC(12V)/27.6VDC(24V) | |||||||||||
Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V), stop charging after 60s alarm | |||||||||||
Solar Charge & Ac Charger | ||||||||||||
Maximum PVArray Open Circuit Voltage | Max. 30V(12V) / 50V (24V) | |||||||||||
Maximum Pv Array Power | 450W(12V)/900W(24V) | |||||||||||
Maximum Ac Charge Current | 15A | |||||||||||
Maximum Solar Charge Current | 20A PWM | 30A PWM | ||||||||||
Maximum Charging Current | 35A | 45A | ||||||||||
Working mode | ||||||||||||
01 mode | AC mains priority | |||||||||||
02 mode | ECO mode | |||||||||||
03 mode | DC battery priority | |||||||||||
Physical | ||||||||||||
Dimension, D*W*H(MM) | 360*33*215 | |||||||||||
G.W.(KGS) | 8.5 | 8.5 | 9 | 9 | 10 | 10 | ||||||
Environment | ||||||||||||
Humidity | 0~95%（NO CONDESNSATION) | |||||||||||
Operating Temperature | 0~60℃ | |||||||||||
Storage Temperature | 0~60℃ | |||||||||||
*Product Specifications Are Subject To Change Without Further Notice | ||||||||||||
Products Description
FAQ
Q1: Does your company also provide other solar products except Pure Sine Wave Inverter?
A1: Yes, we also provide other solar products, like MPPT Solar Controller, poly solar panel, off grid solar inverter, on grid
inverter, battery, portable solar system, solar charger and other accesories
related to the solar power system.
Q2: How to choose a right inverter?
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?
A3: 5 days for sample; 7-15 days for bulk order.
Q4: What is the warranty of inverter?
A4: 1 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
