Машина для маркировки дорог из холодного пластика с ручным нажимом на

Описание и отзывы

Трекер стоимости

Характеристики



1.Description:

It is is a pavement construction machine that is widely used in roads, high-grade roads, parking lots, squares, and runways to draw different restrictions, guidelines, and warnings on the flat ground.

Main Types:





2.Features and Main Parts:

1.More Stable:Compared with the traditional ruling machine,RS-5E is no pneumatic cylinder and have less line pipe, therefore it is more stable and safe.

2.Cost Savings: RS-5E not need to equipped with air compressor, avoid double maintenance, reduce the save maintenance costs, reduce unnecessary trouble, save energy.

3.Simplicity of Operator: RS-5E have reasonable equipment and compact structure, it avoid unwanted weight and machinery.At the same time, RS-5E has few buttons, so it is easy to understand and operation.

4.Regulation of Spraying:.The speed and width of spraying are adjustable, spraying is easy to assemble and disassemble ,it is convenient and simple for equipment to operated.

5.Uniform thickness:RS-5E can spew out uniform thickness of paint,in this way, road surface effect looks great.

6.Light weight:The weight of RS-5E is lighter than other ruling machines,therefore,the actual operation of a lot of effort.

7.High efficiency:In traditional ruling machine on updating and transformation, RS-5E use less energy and improve the efficiency. is cost-effective.





3.Specification:

Model	RS-5A	RS-5E
Size	1800*1080*1130mm	1950*1000*1250mm
Weight	170kg	180kg
Engine	5.5HP gasoline engine	5.5HP gasoline engine
Working Pressure	10~15MPa	10~15MPa
Marking Width	50~500mm	50~600mm
Marking Thickness	0.2~0.6mm	0.2~0.6mm
Spraying Flow Rate	9L/min	11L/min



4.On-site Show:





5.Package:



6.Auxiliary Road Marking Machines

Auxiliary road marking machines mainly including road cleaning machine, high pressure road air blower, waterline pre-marking machine, primer machine and two types of road marking remover. These different machines will work together to complete the road marking construction.







7.Our Certificate:
