Паяльная станция bga для материнской платы ноутбука

Цена:490,00 $ - 500,00 $*

Количество:

Hot sell ACHI IR6500 BGA Rework Station

Simple Description:

Highlights of this ACHI IR6500 DIY IR BGA Reflow Rework Station Price Good

1. USB interface.

2. 2 temperature zones

3. With tempering glass,more uniform heating

4. Hot sale model, praised by many customers.

5. Low cost.

6. Technical support is always available

7. Original Factory, look for worldwide distributors

Main Features:

Where this ACHI IR6500 DIY IR BGA Reflow Rework Station Price Good can be used for ?

1. For repairing Mobile phones

2. For repairing Notebooks/ Laptops/computers

3. For repairing game consoles, especially for XBOX360/PS3/WII

4. For repairing any other mainboards with size from 22x22mm to 500x400mm

5. For preheating chips or mainboards before soldering to improve rework efficiency.

Specifications:

Total Power	1350W
Upper heating	Dark IR 400W
Bottom heating	IR 800W tempering glass is added above bottom heater, heat distribute evenly and improve reworking efficiency
Size of Applicable Chips	≤70mm×70 mm
Size of bottom heating	180mm×180 mm
Size of Upper heating	80mm×80mm
Upper heating position control	Up, Down, Right, Left
PCB fixed platform	Slide Guide Bracket
LED Auxiliary Lighting	Y
Force Air Cooling	N

Programmable	Y
Soft Control	Y, built-in USB connector to connect PC instead of the old RS232
Voltage	AC220V±10%, 50/60Hz
Size of applicable PCB	≤400*305mm
Temperature control Settings	8 levels of (up/down) and constant temperature controls,10 groups storage of curves
Temperature Sensor	OMEGA Thermocouple Wire is more accurate, and more flexible to locate on mainboard
Other Improvment	emergency power switch which can stop the working machine automatically in time when the machine short circuit happens 4pcs jig which can help to fix the mainboard more easily
Dimensions	L475×W480×H420mm
Net weight	17.5kg
