Yunlea ILITEK USB/I2C емкостный сенсорный экран с цифровым преобразователем
- Категория: Touch Screen Monitors >>>
- Поставщик: Shenzhen,Yunlea,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 72.21 $* | 73.27 $* |
| Jul-15-2025 | 59.18 $* | 60.25 $* |
| Jun-15-2025 | 71.42 $* | 72.49 $* |
| May-15-2025 | 71.32 $* | 72.95 $* |
| Apr-15-2025 | 56.77 $* | 57.65 $* |
| Mar-15-2025 | 70.63 $* | 71.11 $* |
| Feb-15-2025 | 69.91 $* | 70.62 $* |
| Jan-15-2025 | 68.40 $* | 69.85 $* |
Характеристики
Product Description
digitizer touch screen 23" with USB/I2C interface
Product Name | 23 inch capacitive touch screen |
Type | P-cap capacitive touch screen |
Structure | Glass+Glass(cover glass+sensor glass) |
Outline dimension | 551.18x334.42mm |
Active area | 511.18x288.42 mm |
Thickness of cover glass | 1.8mm |
Touch solution | COB (chip on the board) |
Touch controller | EETI |
Operating systems | Win 7,Win8,Win CE,Android,Linux |
Interface of CTP | I2C/USB/RS232 |
Surface hardness | 6H |
Transparency | 86% min |
Touch points | 10 touch points |
Operating temp | -20 to 70 degree |
Products Show
Size | Lens's OD(mm) | Lens's VA(mm) | Sensor's OD | Sensor's VA | Thickness of Lens | Ratio | Chip | Interface | |
10.1 | 254.96*172.60 | 217.96*136.60 | 233.96*136.60 | 233.96*170.60 | 1.1 | 16:10 | EETI | I2C/USB/RS232 | |
10.4 | 236.20*178.40 | 213.20*160.40 | 253.02*177.40 | 215.20*162.40 | 1.1 | 4:3 | EETI | I2C/USB/RS232 | |
12.1 | 290.00*220.50 | 246.00*184.50 | 280.00*210.50 | 248.00*186.50 | 1.1 | 4:3 | EETI | I2C/USB/RS232 | |
15 | 346.08*270.02 | 305.00*229.01 | 323.10*251.79 | 307.10*231.07 | 1.1 | 4:3 | EETI | I2C/USB/RS232 | |
15.6 | 387.00*231.00 | 344.00*194.00 | 362.00*222.00 | 346.00*196.00 | 1.1 | 16:9 | EETI | I2C/USB/RS232 | |
17 | 377.00*309.00 | 338.92*271.34 | 363.92*301.34 | 340.92*273.34 | 1.1 | 5:4 | EETI | I2C/USB/RS232 | |
17.3 | 402.00*239.00 | 383.00*216.00 | 399.73*236.92 | 385.00*218.00 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
18.5 | 440.80*271.40 | 410.80*231.40 | 430.80*261.40 | 412.80*233.40 | 1.1 | 16:9 | EETI | I2C/USB/RS232 | |
19 | 421.00*346.00 | 377.32*302.06 | 402.36*334.06 | 379.32*304.06 | 1.1 | 5:4 | EETI | I2C/USB/RS232 | |
19.5 | 463.92*277.34 | 434.92*237.34 | 454.92*262.84 | 436.92*239.34 | 1.1 | 16:10 | EETI | I2C/USB/RS232 | |
21.5 | 524.00*321.80 | 478.00*269.80 | 508.00*303.80 | 480.00*271.80 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
23 | 551.18*334.42 | 511.18*288.42 | 531.18*324.42 | 512.18*290.42 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
23.6 | 555.50*343.00 | 525.50*297.00 | 545.50*333.00 | 527.50*299.00 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
24 | 567.70*350.70 | 533.70*300.70 | 557.70*326.70 | 535.70*302.70 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
27 | 658.00*416.00 | 598.00*336.00 | 640.00*390.00 | 600.00*338.00 | 3 | 16:9 | EETI | I2C/USB/RS232 | |
32 | 765.00*466.50 | 698.70*393.30 | 750.00*450.00 | 704.00*396.00 | 1.8 | 16:9 | EETI | I2C/USB/RS232 | |
42 | 1052.60*645.2 | 930.20*524.20 | 1000*610.00 | 934.20*528.20 | 3 | 16:9 | EETI | I2C/USB/RS232 |
Customized solution
Our Company
Why Choose Yunlea?
(1)13000 Square meter factory,main for CTP and TFT ,larger production capacity ensure the fastest delivery.
(2)High quality Control with CE,ROHS and so on approved.
(3)Precise and advanced equipments
(4)More than 10 years of industry experience and involved main markets all over the world
(5)Dedicated and professional sales team will offer you 24 hours online and immediate service
(6)OEM and ODM welcome,12months warranty on our product
(7)Our mission is to help our customers achieve success, then fulfill our both dreams
Packing & Delivery
Packing Details : Plastic Tray+Anti-Static Foam+Paper Card+Vacuum Bag+Carton
Delivery Details : Shipped in 7 days after payment for sample
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? Do you provide customized touch screen?
A: Yes, we accept sample order.Yes,we can accepted customized your own touch screen.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
