Характеристики


Product Description

6L PET production device/plant/machine 1000BPH

Specification:

FP-500ll PET production device is especially used to produce 10L bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
● Perfect function with econo
mic investment.
● Small size and compact construction with no space waste.
● Easy to operate and maintain ,operation by one person .
● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer’s requirements.

Technique Parameter of PET production device:
\t
Main parameter:
\t
Model
\t
DY-500ll
\t
Container
\t
Product material
\t
PET
\t
Volume
\t
0-5L
\t
output
\t
1000PCS/H
\t
Preform length
\t
15mm-320mm
\t
Preform inner diameter
\t
φ5mm-200mm
\t
Moulding
\t
Max.mould plate Dimenstion (L x W)
\t
520x350mm
\t
Max.mould thickness
\t
180mm
\t
Clamping force
\t
480KN
\t
Mould opening stroke
\t
420mm
\t
 Machine size and weight
\t
Main machine (L x W x H)
\t
1850*610*1700mm
\t
Main machine weight
\t
800Kg
\t
Heater (L x W x H)
\t
1800*610*1400mm
\t
Heater weight
\t
300Kg
\t
Power
\t
40kw
Related Products

neck diameter 28mm 6 cavity full automatic blow molding machine/line/system 1500ML

automatic blow molding machine

2400-7200 bph PLC control automatic blow molding equipment / system

automatic blow molding equipment

High efficiency easy maintenance Blow molding unit

Blow molding unit
Detailed Images
\t
Air compressor
\t
Unit
\t
1.2M3/min 30KG
\t
Volume
\t
M3
\t
1.2
\t
Pressure
\t
Kg
\t
30
\t
Speed
\t
r/min
\t
850
\t
Power
\t
KW
\t
15
\t
Overall Dimension
\t
mm
\t
2000*1100*1600
\t
Weight
\t
kg
\t
620
\t
Refining-Filter
\t
Unit
\t
2.0 M3/min 30KG
\t
Flow capacity
\t
M3/Min
\t
2
\t
Max.work pressure
\t
Mpa
\t
3.0
\t
Inlet Temp
\t
\t
≤50
\t
Cold Medium
\t
mm
\t
750*350*350
\t
Weight
\t
KG
\t
20
\t
Refrigeration Air Dryer
\t
Unit
\t
2.0M3/min 3.0Mpa
\t
Flow capacity
\t
Nm3/min
\t
2.0
\t
W.P
\t
Mpa
\t
3.0
\t
Inlet Temp.
\t
\t
≤80
\t
Dew point
\t
\t
23
\t
Ambient Temp.
\t
\t
≤38
\t
Power supply
\t
V/HZ
\t
220/50
\t
Compressor power
\t
Kw
\t
0.75
\t
Cold Medium
\t
mm
\t
1050×650×1100
\t
Weight
\t
Kg
\t
120
Packing & Delivery

1. the PET production device is packed by wooden case.
2. The delivery date of PET production device is within 30
days after payment.

Company Information

ZhangJiaGang City FILL-PACK Machinery Co.,Ltd. is loacated in Zhangjiagang city which is famous for beverage machinery producer collection. Intergrated the industry advantange and its own development in R&D, production, sales, after sales service, FILL-PACK is ready to serve more and more customers with our full range products and satified service.
FILL-PACK product is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.
At present we produce: production lines for mineral water, pure water, fruit juice, tea drink, milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 80-1200 barrels per hour and various water treatment plants; We provide separate machinery or turnkey project.
Our product pass quality inspection executed by Bureau of Quality and Technical Supervision every year. Our factory is in accordance with ISO9001: 2000 certification system standards and we gain CE certificate for exportation to Euro countries. Our machineries are sold to more than 30 cities in China and over cross to American, Spanish, Hungary, middle east and African countries.
We help to set up your factory as our own home with our pure heart, we do to service, we learn to support!
