Advanced PLC control touch screen Bottle blow molding machine/device/unit 120B/H

Specification:
FP-1
20 Bottle blow molding machine is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
● Perfect function with economic investment.
● Small size and compact construction with no space waste.
● Easy to operate and maintain ,operation by one person.
● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer's requirements.

\t
Name
\t
Item
\t
Unit
\t
Details
\t















Blowing machine
\t
Dimension
\t
mm
\t
2300*750*2100
\t
Bottle volume (max)
\t
L
\t
22
\t
Bottle volume (min)
\t
L
\t
5
\t
Bottle Neck Diameter (max)
\t
mm
\t
90
\t
Bottle Neck Diameter (min)
\t
mm
\t
38
\t
Body Diameter (max)
\t
mm
\t
300
\t
Body Height( max)
\t
mm
\t
550
\t
Number of Cavities
\t
mold
\t
1
\t
Production output
\t
pcs/h
\t
5GALLON:85-90PCS/HOUR
\t
Clamping force
\t
T
\t
20(200KN)
\t
Mold thickness
\t
mm
\t
450(max)
\t
Mold width
\t
mm
\t
430x530
\t
Space between Tie-bars
\t
mm
\t
430*470
\t
Diameter of Tie-bars
\t
mm
\t
63
\t
Scope of Tie-bars
\t
mm
\t
405
\t
Mold stroke
\t
mm
\t
170
\t
Stretching stroke (max)
\t
mm
\t
420
\t
Working pressure
\t
Mpa
\t
0.8-1.0Mpa
\t
Blowing pressure
\t
Mpa
\t
2.0-3.0Mpa
\t
Voltage/Power
\t
V/KW
\t
220V/1KW
\t



Pre-heater
\t
Dimension
\t
mm
\t
2300*750*2100MM
\t
Weight
\t
kg
\t
1600
\t
Voltage/Power
\t
V/KW
\t
380V/28KW
\t
Lamp
\t
PCS
\t
32
\t
Working power
\t
Kw
\t
15kw
Related Products

automatic PLC control hot blowing beverage bottle production line

beverage bottle production line

2400bph 2 cavity beverage bottle production machine/plant/line for water treatment

beverage bottle production machine

4000BPH high output advanced PLC control PET drink bottle production line/oil bottle production plant/PET producing line

drink bottle production line
Detailed Images
Packing & Delivery

1. the Bottle blow molding machine is packed by wooden case.
2. The delivery date of Bottle blow molding machine is within 30 days after payment.

Company Information

ZhangJiaGang City FILL-PACK Machinery Co.,Ltd. is loacated in Zhangjiagang city which is famous for beverage machinery producer collection. Intergrated the industry advantange and its own development in R&D, production, sales, after sales service, FILL-PACK is ready to serve more and more customers with our full range products and satified service.
FILL-PACK product is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.
At present we produce: production lines for mineral water, pure water, fruit juice, tea drink, milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 80-1200 barrels per hour and various water treatment plants; We provide separate machinery or turnkey project.
Our product pass quality inspection executed by Bureau of Quality and Technical Supervision every year. Our factory is in accordance with ISO9001: 2000 certification system standards and we gain CE certificate for exportation to Euro countries. Our machineries are sold to more than 30 cities in China and over cross to American, Spanish, Hungary, middle east and African countries.
We help to set up your factory as our own home with our pure heart, we do to service, we learn to support!

Our Service

1.installation&commissioning

After the equipment arrived at the customer's site. the customer is responsible for unpacking and arranging the equipment according to the placement drawing;Our technician will do equipment set up and commissioning,buyer should offer necessary help if needed

2.Training

We are responsible for offering the technical training to user.Through training,users' technical staff can grasp and the skill of operation and maintenance proficiently.The buyer also can send staff to our company for learning.

3.Quality assurance

The warranty period is 12 months after acceptance chech of the production line.if there is any different between the furnished equipment in the customer's factory and the equipment concerned in the contract.
