Один год гарантии два года оборудование/завод/блок для производства домашних

Один год гарантии два года оборудование/завод/блок для производства домашних

Категория: Stretch Blow Moulding Machines >>>
Поставщик: Zhangjiagang,City,Fillpack,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.72 $*	0.32 $*
Aug-18-2025	0.22 $*	0.37 $*
Jul-18-2025	0.98 $*	0.13 $*
Jun-18-2025	0.88 $*	0.46 $*
May-18-2025	0.23 $*	0.24 $*
Apr-18-2025	0.75 $*	0.29 $*
Mar-18-2025	0.32 $*	0.33 $*
Feb-18-2025	0.64 $*	0.98 $*
Jan-18-2025	0.82 $*	0.52 $*

Характеристики

Product Description

One year warranty two years guarantee PET production equipment/plant/unit

Specification:

FP-500ll Oil Bottle Blowing Machine is especially used to produce 10L bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
● Perfect function with economic investment.
● Small size and compact construction with no space waste.
● Easy to operate and maintain ,operation by one person .
● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer’s requirements.

Technique Parameter of Oil Bottle Blowing Machine:

\t Main parameter:
\t Model	\t DY-500ll
\t Container	\t Product material	\t PET
	\t Volume	\t 0-5L
	\t output	\t 1000PCS/H
	\t Preform length	\t 15mm-320mm
	\t Preform inner diameter	\t φ5mm-200mm
\t Moulding	\t Max.mould plate Dimenstion (L x W)	\t 520x350mm
	\t Max.mould thickness	\t 180mm
	\t Clamping force	\t 480KN
	\t Mould opening stroke	\t 420mm
\t 　Machine size and weight	\t Main machine (L x W x H)	\t 18506101700mm
	\t Main machine weight	\t 800Kg
	\t Heater (L x W x H)	\t 18006101400mm
	\t Heater weight	\t 300Kg
	\t Power	\t 40kw

neck diameter 28mm 6 cavity full automatic blow molding machine/line/system 1500ML

automatic blow molding machine

2400-7200 bph PLC control automatic blow molding equipment / system

automatic blow molding equipment

250ml 300ml 500ml 550ml 600ml semi auto blow molding machine

semi auto blow molding machine

Detailed Images

\t Air compressor	\t Unit	\t 1.2M³/min 30KG
\t Volume	\t M³	\t 1.2
\t Pressure	\t Kg	\t 30
\t Speed	\t r/min	\t 850
\t Power	\t KW	\t 15
\t Overall Dimension	\t mm	\t 200011001600
\t Weight	\t kg	\t 620

\t Refining-Filter	\t Unit	\t 2.0 M3/min 30KG
\t Flow capacity	\t M3/Min	\t 2
\t Max.work pressure	\t Mpa	\t 3.0
\t Inlet Temp	\t ℃	\t ≤50
\t Cold Medium	\t mm	\t 750350350
\t Weight	\t KG	\t 20

\t Refrigeration Air Dryer	\t Unit	\t 2.0M3/min 3.0Mpa
\t Flow capacity	\t Nm3/min	\t 2.0
\t W.P	\t Mpa	\t 3.0
\t Inlet Temp.	\t ℃	\t ≤80
\t Dew point	\t ℃	\t 23
\t Ambient Temp.	\t ℃	\t ≤38
\t Power supply	\t V/HZ	\t 220/50
\t Compressor power	\t Kw	\t 0.75
\t Cold Medium	\t mm	\t 1050×650×1100
\t Weight	\t Kg	\t 120

Packing & Delivery

1. the PET production equipment is packed by wooden case.
2. The delivery date of PET production equipment is within 30 days after payment.

Our Service

1.installation&commissioning

After the equipment arrived at the customer's site. the customer is responsible for unpacking and arranging the equipment according to the placement drawing;Our technician will do equipment set up and commissioning,buyer should offer necessary help if needed

2.Training

We are responsible for offering the technical training to user.Through training,users' technical staff can grasp and the skill of operation and maintenance proficiently.The buyer also can send staff to our company for learning.

3.Quality assurance

The warranty period is 12 months after acceptance chech of the production line.if there is any different between the furnished equipment in the customer's factory and the equipment concerned in the contract.

FAQ

1.Why do you choose our factory?
There are many foreign guests cooperate with our company.We have enough experience and fund to provide you the high-quality products with the best price.

2.How long can you delivery?
About 30 days after we received the deposit(30%T/T in advance,70%T/T before shipment.)

3.How about your after-sale service?
One year repair for free Seller responsible for arrange engineer for installation and guide the workers of buyer how to operate and necessary repair,and give buyer a turnkey project.

4.How long can you finished the installation?
About 10-15 days.If the water and electricity is ready.If you have any questions,please do not hasitate to contact me.

Certifications
