Формовочная машина для выдувания пластиковых бутылок
US $20000-$50000
Машина для изготовления пластиковых бутылок с минеральной водой серии
- Категория: Stretch Blow Moulding Machines >>>
- Поставщик: Taizhou,Waton,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 14280.53 $* | 14994.19 $* |
| Aug-19-2025 | 14160.12 $* | 14868.25 $* |
| Jul-19-2025 | 11880.80 $* | 12474.4 $* |
| Jun-19-2025 | 13920.38 $* | 14616.65 $* |
| May-19-2025 | 12120.12 $* | 12726.78 $* |
| Apr-19-2025 | 13680.58 $* | 14364.35 $* |
| Mar-19-2025 | 13560.75 $* | 14238.51 $* |
| Feb-19-2025 | 13440.53 $* | 14112.80 $* |
| Jan-19-2025 | 13320.55 $* | 13986.6 $* |
Характеристики
Product Description
| Model | QCS-T | |
| Max Production Capacity | 800 | |
| Product | Volume(ml) | 5000 |
| Diameter Max(mm) | 190 | |
| Height Max(mm) | 320 | |
| Mould | Cavity | 1 |
| Thickness(mm) | 280 | |
| Width*Height Max(mm) | 360*360 | |
| Preform | Neck Size Max(mm) | 45-120 |
| Length Max(mm) | 140 | |
| Heat Oven | Lamp Number | 24 |
| Adjust Zone | 3 | |
| Electrical | Power | 380V/50HZ |
| Heating Power | 48 | |
| General Power | 50 | |
| Compresses Air | Blow Compressed | 2.2-3.5Mpa |
| Drive Compressed | 0.8-1.0Mpa | |
| Machine Dimension | Main Machine(kg) | 2500*1600*1950 |
| Machine Weight | Main Machine(kg) | 1950 |
| Machine Packaging Dimensions | Main Machine(kg) | 2550*1650*2000 |
| Machine Weight | Main Machine(kg) | 2000 |
1.Special Design and technology for blowing special design oval bottle, wide neck jar, gallon bottle, etc.
2.Final bottles are discharged by Robot automatically.
3.Special heating and cooled system ensure the performs heated evenly and make high quality bottles.
4.Main parts are processed by heat-treatment, which extend the machine life.
5.All Pneumatic elements are from famous suppliers: PARKER high pressure valve, FESTO low pressure valve, FESTO cylinder, Mitsubishi PLC, KEYENCE sensor, etc.
Related Product
More Product
Packing Of Product
Our Company View
FAQ
1.How to send my enquiry?
You can contact us by email, phone call, Instant Messenger (Whats APP, We Chat, Skype).
2.How long can I get feedback after enquiry?
We will reply you within 10hrs in working day.
3.Where is your factory located? How can I visit there?
Our factory is located in Huang Yan, Tai Zhou City, Zhe Jiang Province, China. There has flight from Shanghai(one hour), Guang Zhou(2 hrs) and Shen Zhen(2 hrs) to our city. Train from Shanghai to our city is 4 hrs. Welcome to visit our factory.
4.Delivery time
Machines & molds order takes 30 days after pre-payment received. Preform orders depends on the qty. Please inquiry sales.
5.What is the package? Is it suitable for shipment?
Machines will be packed by standard wooden case. It is very much strong for oversea transportation. Preforms are packed by standard double layer carton.
6.Payment term
30% by T/T as down payment, balance 70% by T/T or L/C before delivery. We offer credit to customers, in which case the balance payment could be months after delivery. Welcome to inquiry sales.
7.Can I trust you?
Sure, we’re Alibaba verified supplier & Alibaba Trade Assurance Suppier.
8.How long is the warranty for machines?
Machines warranty is 12 months from installation & commissioning.
9.How' s your after-sale service?
Out after sales support and service is second to none and we urgently respond to your queries, if parts are required they would be sent to you by international courier within 48 hrs upon registering your need
10.Can you engineer come to our place to help with machine installation & commission?
Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
