Wood chips dryer/Wood flour dryer/sawdust dryer

 HOT SALE

Air dryer introduction :

  Air dryer is mainly used for the size <5MM, moisture content between 55-35 % wood flour , sawdust , wood chips and other raw materials dried to a moisture content between 13-5 %, refined humidity can be controlled according to customer demand , airflow airflow dryer use instant drying principle , the advantage of direct heating , drying fast , foldable install , space-saving , through this wood powder drying equipment , having finished look clean, shiny, fineness , moisture stable , impurity contamination is small.



Air dryer Scope:

  Scope of this machine is generally a low melting point and its own light weight powder , sheet materials, such as : wood flour , sawdust, wood chips, rice husks,wood shavings , wood , flour, fodder , and other raw materials can also be used starch , rice flour , food, pharmaceutical, chemical and other industries drying drying operations , the equipment with minimum investment , minimum power consumption , minimal manpower and space , the fastest rate , the economic benefits are to obtain the best drying widely used.

Air dryer consists of:

The machine consists of stove, feed port , slagging , drying tunnel , turn feeders, surge bin , a temperature controller , a cyclone , a gate , fans, cleaning equipment , flue pipes and other components.



Air dryer works:

Material from the feed inlet into , ventilation fan in the lead role of high-temperature hot stove , and natural materials along with high-speed fall pulled to the drying tunnel , turn into the feeder and turn the surge bin , since the turning of the material during the operation and and heat flow and has been run from beginning to end material and air temperatures can reach a reasonable state , the entire surface of the material can be sufficiently dried , the final product material line to the discharge port to complete the material , moisture content of the hot gas passing through the cyclone dust after exclusion of dust through the flue gas duct , complete efficient and environmentally friendly drying drying purposes.



Air dryer features:



1 : drying effect , complete granular , powder wet material into a hot gas stream , with stream and thereby obtain dried granular product , material moisture 40% drying time can meet the requirements , and other drying compared machine ( normally takes 2-3 times ) reduces the labor intensity ;

2: The drying time is short , the contact time of the material and the air very short drying time is generally 0.5 to 5 seconds , for heat-sensitive materials or low melting point or decomposition will not cause overheating and affect the quality, with automatic feed, hot air speed airflow material mixing sufficiently large drying strength, low dust , time is short , the thermal efficiency high humidity materials processing capacity , etc;

3 : high thermal efficiency, air drying and the use of materials with the gas stream operations , drying time is short , so you can use high temperature drying , air drying machine is suitable for a wide range of high- yield , precipitation amplitude ;

4 : compact design value ,, low investment and maintenance costs ;

5 : foldable install , space-saving , small footprint .



Air dryer technical parameters :

Finished Products :

Air dryer Equipment :

Air dryer drying technology :

1 , timber materials are generally required to advance the wood flour mill was subject to the dryer feed size .

2 , air dryer productivity : hot air is 180 ℃ , the relative humidity of 35% sawdust or rice husk dried to a humidity of about 10% of the hot air temperature is not lower than 180 ℃ , can reach 300 ℃, according to . hot gas temperature can be controlled drying efficiency .

3 , the fuel can be used: wood ( chopped firewood ) , coal, steam or electric heating .

Air dryer installation test :

1 , the device should be installed on a level concrete foundation with anchor bolts .

2 , the installation should pay attention to the main body vertical and horizontal .

3 , after installation check all parts for loose bolts and host the doors are tight , if requested to tighten .

4 , according to the power equipment configuration power cord and control switch.

5 , checked, empty load test , test the normal production.

Air dryer operating procedures :

1 , the installation is complete , open the fan , check the direction of rotation of the fan and feeding suction port is normal .

2 , check the flange interface , look for leaks.

3 , the separator feed opening tied bag open at both ends .

4 , in addition port was added material to be dried , before drying must screen out chunks of particles , this will help increase the drying speed.

5 , added fuel to ignite in the furnace , the fan turned on , when the wind is at the outlet temperatures up to 150 ℃ , the start cutting, drying .

6 , the timely removal of the bulk material discharging outlet , in order to feed .



Air dryer maintenance:

1 , a day with a soft cloth to wipe the device in order to maintain a neat appearance .

2 , a day before the examination boot triple gas source , when the oil level insufficient add oil and water in the exhaust .

3 , a day to clean up the dust inside the fluff , ensure good ventilation , the equipment to play the best drying results .

4 , monthly maintenance

5, open the lid , use a soft cloth to clean the interior of the device.

7 , check the belt tension , adjust the pulley .

8, after the shake is likely to loose and fell off the site, including electrical wiring , door rocker , pipe joints and so strong.
