Product Description
YT28 Rock Drill
* The rock drill is used for rock drilling, blasting holes and other drilling works in the quarries, small coal mines and other constructions.
Main Features
* 1.Fit for wet drilling in medium-hard or hard rock.
* 2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle and easy to maintain and repair.
* 3.Energy-saving and efficient, long service life of parts, parts highly interchangeable and reliable performance.
* 4.YT28 differ form similar products particularly in its high efficiency, strong flushing and powerful torque.
* The rock drill is used for rock drilling, blasting holes and other drilling works in the quarries, small coal mines and other constructions.
Main Features
* 1.Fit for wet drilling in medium-hard or hard rock.
* 2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle and easy to maintain and repair.
* 3.Energy-saving and efficient, long service life of parts, parts highly interchangeable and reliable performance.
* 4.YT28 differ form similar products particularly in its high efficiency, strong flushing and powerful torque.
Model | YT28 | |
Weight | ≈ 26 kg | |
Length | 661mm | |
Cylinder dia | 80mm | |
Piston stroke | 60mm | |
Air pressure | 0.4- 0.63MPa | |
Impact frequency | ≥ 37 Hz | |
Air consumption | ≤81L/S | |
Air pipe (inner dia ) | 25mm | |
Water pipe (inner dia ) | 13mm | |
Drill bit dia | 34-42mm | |
Shank dimensions(hex×length) | 22×108±1mm | |
The function specification hatis Air pressure | 0.63Mpa | |
FT160BD Air leg(short) | ||
Length | 1400mm | |
Push stroke | 965mm | |
Cylinder dia. | 65mm | |
Weight | ≈ 14.4 kg | |
FT160 Air leg(long) | ||
Length | 1800mm | |
Push stroke | 1365mm | |
Cylinder dia | 65mm | |
Weight | ≈ 169 kg | |
FY200B oil reservoir | ||
Oil capacity | 200ml | |
