2 4 В 6 мм Умная Ручка для защиты от близорукости маленький шаговый сервопривод 5 в постоянного тока микро тихий двигатель 12 редуктор с
- Категория: Шаговый электродвигатель >>>
- Поставщик: Shenzhen,Zhaowei,Machinery,&,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.20 $* | 0.86 $* |
| Aug-15-2025 | 0.72 $* | 0.1 $* |
| Jul-15-2025 | 0.54 $* | 0.7 $* |
| Jun-15-2025 | 0.47 $* | 0.94 $* |
| May-15-2025 | 0.54 $* | 0.24 $* |
| Apr-15-2025 | 0.55 $* | 0.23 $* |
| Mar-15-2025 | 0.40 $* | 0.61 $* |
| Feb-15-2025 | 0.44 $* | 0.68 $* |
| Jan-15-2025 | 0.46 $* | 0.11 $* |
Характеристики
provide micro gear gearbox motor drives system custom services. | |||
| dc gear motor(size) | Rated Voltage | speed | load current |
| 3.4mm | 1.5-5V | 3.5-300rpm | 100mA-220mA |
| 4mm | 2.4-300rpm | 340mA | |
| 6mm | 3 – 12V | No Load Speed: 11-3824 rpm Rated Load Speed: 10-3229 rpm | No Load Current: 40 mA Rated Load Current: 100 mA |
| 8mm | 14 – 3111 rpm | Gear Stages: 1 – 4 | |
| 10mm | 3-24 V | No Load Speed: 20-4318 rpm Rated Load Speed: 18-3625 rpm | No-load Current: 60-80 mA |
| 12mm | 7 – 254 rpm | Gear Stages: 1 – 4 | |
| 16mm | No-load Speed: 4-1,373 rpm Rated Load Speed: 3-1,125 rpm | No-load Current: 85-110 mA Rated Load Current: 130-150 mA | |
| 20mm | No-load Speed: 7-1,636 rpm Rated Load Speed: 7-1,420 rpm | No-load Current: 70-90 mA Rated Load Current: 125-130 mA | |
| 22mm | No-load Speed: 6-1,886 rpm Rated Load Speed: 5-1,675 rpm | No-load Current: 100-120 mA Rated Load Current: 295-300 mA | |
| 24mm | No-load Speed: 5-1,460 rpm Rated Load Speed: 4-1,259 rpm | No-load Current: 70-80 mA Rated Load Current: 215-220 mA | |
| 28mm | 5 – 1658 rpm | 300mA max Gear Stages: 1 – 4 | |
| 32mm | 5 – 1348 rpm | Gear Stages: 1 – 4 | |
| 38mm | No-load Speed: 3-1,386 rpm Rated Load Speed: 3-1,294 rpm | No-load Current: 315-335 mA Rated Load Current: 1,679-1,684 mA | |
