Машина для производства пластиковых резервуаров для воды Juneng
US $35000-$38000
30 литров 60 машина для выдувного формования пластиковых
- Категория: Экструзионно-выдувные формовочные машины >>>
- Поставщик: Zhangjiagang,U,Tech,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 14280.0 $* | 14994.69 $* |
| Aug-20-2025 | 14160.65 $* | 14868.72 $* |
| Jul-20-2025 | 11880.49 $* | 12474.97 $* |
| Jun-20-2025 | 13920.85 $* | 14616.7 $* |
| May-20-2025 | 12120.66 $* | 12726.98 $* |
| Apr-20-2025 | 13680.60 $* | 14364.75 $* |
| Mar-20-2025 | 13560.83 $* | 14238.76 $* |
| Feb-20-2025 | 13440.71 $* | 14112.68 $* |
| Jan-20-2025 | 13320.63 $* | 13986.72 $* |
Характеристики
30 liter 60 liter plastic bottle extrusion blow molding machine
1.Program controlling with Japan Mitsubishi PLC; complete machine communication, parameter setting / modification and menu displaying with the Taiwan Hitech liquid crystal display and touch screen; every parameter could be set and modified directly with the complete obstacle self-diagnosing function, menu operated directly and conveniently.
2.Central incoming die head, totally eliminating the converging line of products, the surface is colorful and uniform; this die head is able to be used to match polyethylene, polypropylene and so on;
3.According to the different product, there is one series of die head for choice, such as double die (center distance: 150mm), Tetra-die (center distance: 80mm)
4.Drive mode: inverter + hard gear surface decelerator;
5.Control the hydraulic system with imported proportional valve, ensuring the action steady, accurate and energy saving.
Blow molding machine Specifications
Main Parameters | Unit | BST-65 |
Max. Product Volume | (L) | 5 |
Dry Cycle | (pcs/h) | 700×2 |
Screw Diameter | (mm) | 65 |
Screw L/D Ratio | (L/D) | 24 |
Screw Drive Power | (KW) | 22 |
Screw heating Power | (3ΦW) | 7.2 |
Screw Heating Zone | (Zone) | 3 |
HPDE Output | (kg/h) | 90 |
Oil Pump Power | (KW) | 7.5 |
Clamping Force | (KN) | 65 |
Mold Stroke | (mm) | 148-508 |
Max. Mold Size | (W×H)(mm) | 380×390 |
Max. Die Diameter | (mm) | 145 |
Die Heating Power | (4ΦKW) | 2.5 |
NO. of Heating Zone | (Zone) | 3 |
Blowing Pressure | (MPa) | 0.6 |
Air Consumption | (M3/min) | 0.6 |
Cooling Water Pressure | (MPa) | 0.3 |
Water Consumption | (L/min) | 60 |
Machine Size | (L×W×H)(m) | 2.9×2.1×2.7 |
Machine Weight | (Ton) | 7.8 |
1. Electric part
Part name | Brand |
Computer Program controlling | Japan ,MTSUBISHI PLC Taiwan Hitech liquid crystal display and touch screen |
Temperature control part | Japan, OMRON |
Proximity switch | Taiwan ,RIKO |
Contactor switch | France, SCHNEIDER |
Electric motor | Germany, SIEMENS(SSML) |
Power supply | Taiwan ,MEANWELL |
Inverter | Taiwan ,DELTA |
Hydraulic part
Part name | Brand |
Pump | Taiwan ,HIGHTECH |
Valve | Taiwan ,NORTHMAN / Japan,Yuken |
3,Pneumatic part
Part name | Brand |
Air Valves | Taiwan ,AIRTAC/Germany, FESTO |
Our Services
What service U Tech Machine Co.,Ltd can offer you ?
• Well-trained & experienced staff are to answer all your inquiries in English and Chinese
• 24 hours for engineer response (all services part 5days in customer hand by Intl' courier).
• 2 Years guarantee
• Your business relationship with us will be confidential to any third party.
• Good after-sle service offered, please get back to us if you got any questions
FAQ
Q1:Are you a trading company or a manufactory?
A1:We are a manufactory,can give u best service .
Q2:What’s your guarantee or the warranty of the quality if we buy your machines?
A2:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years
Q3:When can I get my machine after I paid?
A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives?
A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts?
A5:After we deal down all the things , we will offer you a spare parts list for your reference.
Welcome To Visit Zhangjiagang U Tech Machine Co.,Ltd!
