General introduction:

Advance boat gearbox HC138 ratio 2:1-4.5:1 electical control

Marine Gearbox HC138 is suitable for medium and small fishing, transport, tug, traffic and passenger boats.

Marine Gearbox HC138 possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and one-stage transmission, featuring in small in volume and large in ratio.



Parameters:



Input speed	1000-2500r/min
Reduction ratio	2.0,2.52,3.00,3.57,4.05,4.45	Trans. capacity	0.110kw/r/min
Control way	Push-and-pull flexible shaft, electrically, pneumatically
Rated thrust	30KN
Center distance	225mm
L×W×H	520×792×760mm
Net weight	360kg
Flywheel	6135Ca,SAE14,11.5
Bell housing	6135Ca,SAE1,2,3







Our export team:

Service:

1, Quality is our culture. Engines Guarantee within 3 years except quick wear parts.

2, Delivery time within 10-15 days.

3, After sale service: 24 hours hot line, 7 days per day. Email response within 2 hours.

4, All the cargos ordered had been insured for free to customers.

5, Special case and color painted can be made.



Quality assurance:

1, Engine assembly assure 3 years.

2, Marine class certificate and VCA iternational approve is available.

3, Three party inspection can be arranged.
