                  Heat shrink wraparound heat shrink sleeve for Cable Repair cable repair sleeve





CYG heat shrinkable sleeve for cable repair sleeve is mainly used for repairing outer/inner sheath/core damages on a HV cable and LV cable.





CYG cable repair applied heat shrink wraparound sleeve is made from cross-linked polyolefin which equals or exceeds the material properties of the original cable jacket. CYG heat shrinkable wraparound sleeve is widely used for protecting cable against corrosion on metallic parts of the cable that are exposed to the outside too.







Features of heat shrink sleeve for cable joint:

Material: cross-linked polyolefin, inner coated with hot-melt adhesive

Standard color: black

Highlights: easy operation, wide range of selection, fit every occasion, excellent water repellency

Operating temperature:-40~+65°

Shrink temperature:200°





RSW heat shrinkable sleeving for cable Joint and cable repair Specification:

Selection	Supply Size	Diameter after Being Shrunk	Cable’s diameter (mm)
RSW 28/6	22	6	7~15
RSW 36/10	36	10	12~20
RSW 50/15	50	15	18~40
RSW 60/18	60	18	20~50
RSW 70/22	70	22	25~60
RSW 80/25	80	25	30~70
RSW 100/30	100	30	35~90
RSW 135/38	135	38	40~120
RSW 164/45	164	45	50~150
RSW 185/55	185	55	65~165
RSW 200/60	200	60	80~180
RSW 220/65	220	65	90~200
RSW 240/70	240	70	100~220
RSW 260/75	260	75	120~240
RSW 280/80	280	65	140~260
RSW 300/85	300	65	160~280

Length: 250mm,500mm,750mm,1000mm,1500mm,2000mm





CYG Cable heat shrink wrapround sleeve Technical Data

Item	Test Method	Typical Data
Tensile strength	ASTM D2671	≥ 17MPa
Tensile strength after aging	ASTM D2671	≥ 14MPa
Elongation at break	ASTM D2671	≥ 350%
Elongation at break after aging	ASTM D2671/150°, 168hrs	≥ 300%
Density	ASTM D792	0.94g/cm3
Longitudinal shrinkage	UL224	< 5%
Dielectric strength	IEC243	≥ 36kV/mm
Volume resistivity	IEC93	≥ 10 14 Ω · cm
Copper stability	ASTM D2671	Pass
Water absorptive	ISO 62/23°, 14days	< 0.15%
Low Temperature Flexibility	ASTM D2671	No cracking
Resistance to fungus and decay	ISO 846	Pass
