Характеристики
(1)Engine:FOTON ISUZU
(2)Alternator: Stamford or Stamford Copy
(3)Power:15-36KW
(4)Same Technology as ISUZU
Products Features
- Soundproof
- With ATS OR NO
- Safeclean Utilities
- Different colors can be choosen
- Product Origin China
-Rated output power 25kva---45kva
| GENSET MODEL | FSH-20F | |
| RATED OUTPUT(KVA) | 25KVA | |
| MAX OUTPUT (KVA) | 27.5KVA | |
| PHASE | THREE-PHASE | |
| RATED VOLTAGE(V) | 50HZ /400V 1500RPM | |
| RATED CURRENT(A) | 36A | |
| GENSET DIMENSIONS(MM)(open) | 1626×770×1006 | |
| GENSET DIMENSIONS(MM)(silent) | 2080×980×1200 | |
| WEIGHT(KGS) | 840 | |
| ENGINE | TYPE | 4JB1 |
| 12h POWER (KVA) | 30 | |
| 1hour Power (KVA) | 33 | |
| COMPRESSION RATIO | 18.2:1 | |
| FUEL CONSUMPTION(g/kw.h) | ≤230 | |
| DISPLACEMENT(L) | 2.771 | |
| STARTING TYPE | Electric starting/DC12V | |
| Bore×Stroke (MM×MM) | 93x102 | |
| CYLINDER NUMBERS | Inline4-cylinder, direct injection, water cooling | |
| NET WEIGHT(KG) | ≤230 | |
| OVERALL DIAMENSIONS(MM) | 738*601*682 | |
| ALTERNATOR | TYPE | Copy stamford --184F |
| RATED POWER(KVA) | 27.5 | |
| MAX POWER(KVA) | 30 | |
| POWER FACTOR (cos Ø) | 0.8 | |
| EXCITATION MODE | single-bearing with SAE , Brushless sychronous , Three harmonic exciting, | |
| AVR MODEL | SX460 | |
| INSULATION CLASS | H CLASS | |
| IP LEVEL (PROTECTION) | IP23 | |
| CONFIGURATION TYPE | IMB35 WITH FLANGE, 2/3 pitch design | |
| DIMENSION(mm) | 635*500*580 | |
| weight (KGS) | ||
