   High Efficiency Marine Condenser Titanium Twisted tubel Heat Exchanger

How does our heat exchanger work?

Refrigerant vapor flows through the titanium twisted tube inside in a counterflow direction to the liquid refrigerant flowing in the plastic cabinet between the inner tube and outer shell. This counterflow path provides the greatest temperature difference between the two refrigerant streams to yield optimum heat transfer. To further maximize heat exchanger performance with minimum size, the inner tube is convoluted to impart turbulence to both refrigerant flows while the straight-through design helps maintain low refrigerant pressure drops.





Working condition:

·Water temperature: within 30°C

·Water pressure for testing: 5bar

·Gas pressure for testing: 35bar

Titanium is a much stronger material that is virtually impervious to the chemicals used in the pool water. Some companies use Cupronickle heat exchangers. This used to be the norm but they are more vulnerable to corrosion, perforation and system failure.

Only Titanium can stand up to the corrosive effects of salts and chlorine in swimming pool water. There is a10 Year Limited Warranty on titanium heat exchanger coils.

Description:

·Water side: with high pressure resistance PVC shell tube for body and PVC plate for up and down cover

·Green material: pass SGS and RoHS, safe for environment

·Refrigerant side: with titanium tube bending into coil

·With strong anti-corrosion

·Widely used in the sea water and some chemical acid

·Can solve the problem of the corrosion of the copper material

·Surface: not easy for oxidation

·Hard to dirty don't need to worry about its clean tighten between coil and coil by the nylon cable ties so can reduce the moving





A Yes. Our web www.fsnantai.com,E-catalogue ,please contact us directly.
Q3.Is there any discount of the titanium heat exchangers?
A. Yes. Bigger quantity will get lower discount.
Q4.What is the MOQ?

A.We accept loose quantity order,mixed order,any sample orders.

Q5.What information needed if I want a quotation?
A .Type of heat exchangers,  Material , Heating Capacity,Water Flow,Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
Q6. Can we visit your company/factory before place the order?
A. Yes. Welcome anytime.
