Индукционная плавильная печь 5 кВт для золота и
- Категория: Industrial Furnace >>>
- Поставщик: Jiangxi,Jinshibao,Mining,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.20 $* | 0.45 $* |
| Aug-19-2025 | 0.96 $* | 0.45 $* |
| Jul-19-2025 | 0.32 $* | 0.23 $* |
| Jun-19-2025 | 0.33 $* | 0.40 $* |
| May-19-2025 | 0.37 $* | 0.30 $* |
| Apr-19-2025 | 0.25 $* | 0.73 $* |
| Mar-19-2025 | 0.94 $* | 0.63 $* |
| Feb-19-2025 | 0.27 $* | 0.69 $* |
| Jan-19-2025 | 0.68 $* | 0.83 $* |
Характеристики
Product Description
5KW Induction Melting Furnace For Gold And Platinum
| 1.Description of induction melting furnace |
We combine technological excellence with our core expertise along with involving simplistic solutions to bring out the range of melting furnace that are very efficient and user friendly machinery.
The industry can recover more precious metals & reduce the losses of the organization.it also can improve the profit margin of the cost of high speed furnaces like induction.
The melting furnace has absolutely simple operations, extremely low maintenance &operation cost to help increase the profit level of organization.
| 2.Features of induction melting furnace |
1) Fast heating, wide heating,
2) Comprehensive protection ,Optional Induction Furnace,Strong construction
3) Easy installations. Easy operation, No Maintenance Cost
4) High effectiveness,Low power consumption,Durability
5) Small size and light weight, Environmental protection, Noiseless performance
6)Elimination of high voltage
| 3.Machine power of induction melting furnace |
1) Induction heating: mainly by crucible to precious metal in an instant , then smelting, refining,casting and other processes.
2) For the precious metals: platinum, palladium, rhodium, gold, silver, copper. steel, gold powder, sands, tin, tin slag ash all these melting point metals.
3) A single molten metal quantity:1kg-50kg and a single melting time:2-20 minutes.
4) The Max. furnace temperature up to 1500-2000 degrees.
5) Commission for the mummer of ash – like powder high up to 97%.
| 4.Water cooling illustration of induction melting furnace |
| Water feeding temperature | <50°C |
| Pressure | >0.1MPa |
| Flow | 5-20 L/Min |
| Temperature of discharging water | <70°C |
| Water requirement | clean soft water |
| 5.Specification of induction melting furnace |
| Model | 15A | 25A | 35AB | 45AB | 60AB | 80AB | 100AB |
| Power | 2kw | 5kw | 10kw | 15kw | 20kw | 30kw | 45kw |
| Voltage | 220V | 380V | 380V | 380V | 380V | 380V | 380V |
| Weight | 15KG | 25KG | 35KG | 70KG | 70KG | 90KG | 120KG |
| Smelting capacity | 1-2 kg | 1-4 kg | 1-8 kg | 1-15 kg | 1-25 kg | 1-40 kg | 1-50 kg |
| Max processing time | 5Min | 5Min | 10Min | 15Min | 20Min | 30Min | 40Min |
| High Frequency | 30 - 50KHZ | ||||||
| Middle Frequency | 1 - 15KHZ | ||||||
| 6.Types of induction melting furnace |
1) All-in-one type of melting furnace
2) Auto-tilting melting furnace
| 7.Crucibles of induction melting furnace |
The most widely used crucibles for melting furnace are the pure graphite type and ordinary type crucible.
We could also supply to you the crucibles as per your requirements.
1)Graphite crucible:Suitable for gold, silver, copper. steel, gold powder, sands, tin etc, easy to heat up.
2)Silica crucible: Suitable for melting platinum,
3)Ziconia crucible: More durable than others.
| 8.Stock of induction melting furnace |
| 8.Application of induction melting furnace |
Packaging & Shipping
| 9.Packing of induction melting furnace |
| 10.Trade terms of induction melting furnace |
Payment details | Usually paid by T/T or L/C |
| By T/T 30% deposit and balance before shipment. | |
| We will send the goods picture to you once commodity ready. | |
| Packing details | By LCL or FCL(20'/40'GP) container. |
| LCL with steel support seaworthy packing | |
| Export software scientifical loading work | |
| Shipment details | Sea and air shipment available |
| MSK / MSC/ APL/ EMC/ WANHAI /KLINE | |
| We will send the shipping notice to you once goods loading. |
FAQ
Q1. Are you a manufacturer or trading company?
A: We are a manufacturer of mining equipment. All process finished in our house, welcome to visit us at any time!
Q2. Where is your factory located? How can I visit ?
A: Our factory is located in Shicheng County, Jiangxi Province, China.
You could fly to Ganzhou airport or other airport of China. Then we will pick you up to our factory.
Q3. What is your MOQ of each item?
A: 1PC, OEM is also supported.
Q4. May I know more infomation about your product?
A: Yes, please visit us
Q5: What is the lead time?
A: Usually, 7-30 days after deposit confirmation, it will be based on different machines.
Q6: What is your loading port?
A: Xiamen, Shenzhen, Guangzhou, Shanghai, ect.. based on your requirements.
Q7. Why choose you as supplier?
A: 1. High quality & most competitive price
We are a factory who could provide the lowest price to you.
We are top 3 and with more than 20 years experiences in mining equipment.
2. Fast delivery--Goods will be shipped within 7 - 30 days based on order quantity.
3. Best service--Replying emails & solving questions timely. Delivery and update information on time.
We also support below services:
1). Training & after-sale service
Training FREE to every customer. For example: installation, maintenance, or proper use of our company machines.
1year warrantee to make sure your machine runs consistently and keep certain inventory level of spare parts.
2). If you are new for this kind of business, I will help you
We can provide you with the pre-services of design scheme for complete production lines, spot inspection and operator training.
