Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15
Автоматическая передвижная сварочная машина для брезента hf мощностью 15

Автоматическая передвижная сварочная машина для брезента hf мощностью 15


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 0.34 $* 0.31 $*
Aug-15-2025 0.65 $* 0.29 $*
Jul-15-2025 0.17 $* 0.74 $*
Jun-15-2025 0.15 $* 0.97 $*
May-15-2025 0.58 $* 0.23 $*
Apr-15-2025 0.31 $* 0.85 $*
Mar-15-2025 0.7 $* 0.37 $*
Feb-15-2025 0.30 $* 0.82 $*
Jan-15-2025 0.32 $* 0.89 $*

Характеристики





Products Description


High frequency welder was developed specifically for production of large format Stretch Ceiling (French Ceiling) interior design elements.The machine is equipped with special high precision linear motion gear controlled by frequency inverter to achieve a perfect continuous weld "invisible seam" weld.

Tarpaulin welding machine is equipped with special deep and wide trough behind the electrode for material storage and handling. Machine has optional smooth glide wheels for easy movement in-around welded fabric, or relocation to a desired place in manufacturing hall.

This type machine has HF power output from 8 to 25 kW for heavier production loads and reinforced heavy duty fabrics, effectively providing between up to larger welded surface with one weld cycle.






Optional features / tooling

 * Precision linear motion with frequency inverter
* Programmable automatic linear weld cycles
* Work table length up to 25 m with optional
* High HF weld efficiency and speed of production
* Universal usage for PVC film and harpoon welding
* Easy material positioning table with laser guides
* C-frame strong structure for excellent work ergonomics
* Safe anti-spark safety system
*Auto-tuning system could be an optional
* Smooth power output settings
* Touch screen HMI and programmable PLC




Main Applications:
* PVC Stretch Ceilings interior design elements
* Indoor and outdoor lightning fixtures
* 3D and molecular decoration structures
* Advertising signs and billboards
* Protective clothing
* Reflective materials and signage




PRODUCT SPECIFICATIONS


No
Item
Data
1
8Power
8KW
10KW
12KW
15KW
25KW
2
Welding length
800MM
1000MM
1000MM
1200MM
1200MM
3
Welding width
depends on length
4
Welding pressure
750kg
1200kg
1200kg
1200kg
1200kg
5
Press stroke
150mm
6
Deep trough
500mm
7
Working table
3 meter as one segment
8
Voltage
380V 50HZ / customized


Certifications




Recommend Products




Company Profile


ShenZhen Sinopwr Ltd is specialized to manufacture plastic welding machines .Our machines consist of high frequency welding machines, ultrasonic plastic welding machine, heat sealing welding machine, blister packaging machines,etc. We also have designed and manufactured a great number of welding machines according to specific customer's needs.
It's our honor and We are ready to be your partners for the win-win cooperation and mutual benefits.






Packing & Delivery


* Thicker base plate, ensure support strength, and your machine will not be hurt by forklift.

* Wrapping film and desiccant, protect your machine from moisture.

* Standard exported wood cases(multi-layer board).




Our Service


Pre-sales service
1. Professional engineers help to recommend suitable machine according to your requirements.
2. Always welcome to visit our factory. Or VR video is available.
3.Providing sample photos, testing video of similar cases for your reference.
Sales-Service
1. Sending photos,video of your machine manufacturing progress.2. Sending your machine finished photos,video.
3. Sending test videos or remote live video with you to test your machine.
4. Synchronous teaching guidance while testing your machine.
5. Sending your machine package photos
After- sales Service
1. Prepare extra spare parts, wearing parts for you, shipped with your machine.
2. One year Warranty(except wearing parts and human caused)
3. Providing lifetime technical support for you.
4. 7*24 hours service, timely solve working problems.
5. Our engineers are available to serve on abroad


Our Advantages


1.We are manufactures that could make the machines based on customer requirements.
2.We have the mold department that could apply one step solution for products.
3. We could apply customer's site installation, training & maintenance.
4. We have Online service by Email, Video Online for basic setup and repairs
5. 12 months warranty for machine,entire life tech support.
