Amalog мультиметр YX-3600TREB со светодиодной подсветкой и

Amalog мультиметр YX-3600TREB со светодиодной подсветкой и

Категория: Multimeters >>>
Поставщик: Wenzhou,Habo,Technology,Co.,Ltd.

Цена:3,30 $ - 3,50 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-16-2025	4.56 $*	4.23 $*
Jul-16-2025	3.74 $*	3.84 $*
Jun-16-2025	4.82 $*	4.81 $*
May-16-2025	4.0 $*	4.48 $*
Apr-16-2025	3.56 $*	3.72 $*
Mar-16-2025	4.87 $*	4.34 $*
Feb-16-2025	4.33 $*	4.19 $*
Jan-16-2025	4.62 $*	4.65 $*

Характеристики

1.Specifications OF MODEL YX360TREB

Measure AC&DC voltage, DC current, resistance, AF level, transistor parameter, load current, load voltage, capacitance, inductance
Excellent DC resolution factor of 2mV and expanded resistance measurement from 0.2Ω to 20MΩ
Series capacitor terminal (OUTPUT) blocks DC to enable measurement of only AC components
Continuity checking with an LED indicator &BUZZER
A large and bright meter with a scale length of 80mm and ifs sensitivity of 44uA at full scale
diode protection and overload protection fuse
Measures hFE to 1000 using optional TR connector

Product Description

Model Name:	YX-3600TREB
Color:	Black
Size weight:	14810035mm
DCV:	100m/500m/2.5/10/50/250V/1000V ± 4%
ACV:	10/50/250V/1000V ± 5%
DCA:	50u/2.5m/25m/250mA ±4%
Resistance:	2K/20K/200K/2M/20MΩ ± 4%
dB:	-10~+62dB
L1:	150u/1.5m/15m/150mA
HFE:	0~1000(with TR connector)
Power supply:	9V Battery+1.5V Battery*2
Packing details:	20PCS/CARTON G.W./N.W.:12/11KG MEAS:3938.531CM
