Машина для экструдирования

Type

XJ-150

Forms of screw andscrew thread

Double head unequal-depth

Screw diameter(mm)

150

Length-diameter ratioof screw(L/D

4.43

Compression ratio

1.34

Rotary speed of screw(r/min)

20-26

Motor power(kw)

Frequency control 55kw/motor commutator18.3-55kw

Production capacity(kg

700-1200

Steam pressure

0.6

Cooling water pressure

0.2-0.3

Weight(kg

5000

Price (FOB Qingdao)

(no including machine-head)

Note:

1. The motor made in Qingdao, frequency control of motor speed.

2. The screw made in Hohhot China, the material for 42 Chromium molybdenum

3. Warranty: 1 year.

4. we also can according to the customers' requirement, and manufacture the non-standard type of the machine.
