Светодиодный индикатор BA9S/E10, неоновая лампа типа fust
US $0.10-$0.15
BA9S/E10 светящиеся лампы в пластиковом корпусе держатель и неоновый
- Категория: Неоновые лампы и трубки >>>
- Поставщик: Yancheng,Ada,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.44 $* | 0.59 $* |
| Aug-17-2025 | 0.11 $* | 0.44 $* |
| Jul-17-2025 | 0.89 $* | 0.80 $* |
| Jun-17-2025 | 0.11 $* | 0.30 $* |
| May-17-2025 | 0.32 $* | 0.7 $* |
| Apr-17-2025 | 0.2 $* | 0.32 $* |
| Mar-17-2025 | 0.26 $* | 0.40 $* |
| Feb-17-2025 | 0.30 $* | 0.72 $* |
| Jan-17-2025 | 0.57 $* | 0.23 $* |
Характеристики
BA9S/E10 plastic shell glow lamps,lamp holder and neon gas
| TYPE | BREAKDOWN V(Max) | CURRENT | LIFE | APPLIED VOLTAGE | SERIES RESISTANCE | LAMP SIZE | LEAD WIRE | |
| D | L | |||||||
| VAC | mA | h | VAC | KΩ | mm | mm | ||
| ND1 | 135 | 2 | 25000 | 220 380 | 150 | 13.5±0.5 | 38.5±1.5 | E14/20 BA15d/19 |
| ND2 | 135 | 2 | 25000 | 220 380 | 150 | 11±0.5 | 33.5±1.5 | E10/13x11 |
| ND3 | 135 | 2 | 52000 | 220 380 | 150 | 8.5±0.5 | 28.5±1.5 | E10/13 BA9S/14 |
ND1 :Plastic shell neon lamp
ND2:Led indicator light
ND3:Fust type neon lamp series
Plastic shell neon lamp is assembled by neon lamp ,fluorescent lamp ,lamp holder ,series resistor and plastic bracket.
It can be used directly in the lampstand of the circuit without out -connected resistance ,safe and convenient .
It has two kinds:red one and green one,which also can be divided into two:screw socket (BA9S/14).T
he service voltage is 100-380V.This also can be realized on LED verson.
Fuse type neon lmap is consist of nickel-plating copper caps,transparent tube ,neon lamp and resistor,with transparency,safety character.
It is the best indicator for the electric test pencil.
Yancheng Ada Electronics Co.,Ltd.
International Dept: Room 2103, Jiangsu Yishiyuan Mansion, No.95 North Zhongshan Road,NANJING,JIANGSU,CHINA
ZIP CODE:210029
Factory add: XinXing Industrial Zone, Xinxing Town, Tinghu District,Yancheng, Jiangsu, China
Contact person: Jenna
Tel: 0086-25-84692557
Mobile: 0086-17715254524
Fax: 0086-25-84200806
http://www.adalamp.cn
Ordering guide(Indicator light &Signal units)
If you are satisfied with our products and service,please leave us positive feedback and welcome to contact us for the details.
If you are dissatisfied for any reason,plese give us THE OPPORTUNITY TO MAKE THINGS RIGHT before you leave negative/neutral feedback. Your opinions are very important to us.
When enquiry or order,pls choose following items:
Code | ||
Ligh source | Filament lamp | 6v/12v/24v |
Neon and fluorescent | 110/250/400v | |
LED | 3/6/12/24/110/220/400v | |
Color of lens | White( ) Red( ) Orange( ) Creen( ) Bule( ) | |
Color of lamps | White( ) Red( ) Orange( ) Creen( ) Bule( ) | |
Cables | Material | ( )PVC ( )SILICONE |
Section | ( )0.25mm2 ( )0.5 mm2 or on request | |
Length | ( )50mm ( )75mm ( )100mm ( )125mm ( )Xmm | |
| Or TABS | 4.8 or 6.3 | |
| Terminal | ( )Yes ( )No If yes,please show the terminal photo or drawing | |
