Volvo Penta Engine Manufacturer



Our factory Have NENJO, Volvo, Deutz, Doosan, Shangchai, Weichai, Jichai etc brand generator set, and silent/low noise/sound-proof, mobile/ trailer generators.



We pass CE,ISO,CQC certificate.  genset power range: 25-2000kva, alternator power range: 6.5-1760kw.



You can choose "Stamford","Marathon","NENJO" etc. alternators!!!





We are manufacturer!!!

Technical parameters of diesel generator sets:
Generator Set
Generator Model				GF120V
Prime Power				120kw
Rated Voltage				400/230V
Frequency				50Hz
Power Factor				0.8(lagging)
Dimension (L×W×H) (mm)				2400*870*1450 mm
Genset weight (kg)				1560 kg
Diesel Engine
Brand				VOLVO
Type				TD731GE
Number of Cylinders				6
Rotating Speed				1500RPM
Cycle				Four stroke
Cooling Method				Water Cooling
Bore×Stroke(mm)				108*130
Displacement(L)				7.15
Compression Ratio				18.0:1
Speed Governor				Electrical
Cooling System				Water-cooled
Total Lubrication System Capacity (L)				/
Fuel Consumption at 100% Load				215 g/kwh
Starting Method				24V Electrical starting
Alternator
Brand				NENJO
Model				HJI-120
Prime/Standby Power				120kw
Connecting Type				3 Phase and 4 Wires
Number of Bearing				single
Protection Grade				IP23
Altitude				≤1000M
Exciter Type				Brushless ,Self-exciting, AVR automatic voltage regulating
Insulation Class				H





  A: Test before shippment

- Each Generator Set shall be put into commission more than 4 hours totally, tested on idle load, fully load and  10% overload.- Noise level shall be tested.

- All of the meters on the control panel shall be tested.

- The appearance of the Set and the label, nameplate shall be tested. "

-Voltage available: 50Hz: 380-400-415V/ 220-230-240V; 60Hz: 220-380-416-440-480V/ 110-208-220-

240v.Any special voltage is alse available as cilent's request



B: Packing & Warranty

- Packing: Wooden Case, Plywood or Metal Case.

- Delivery Time: Less than 25 working days after receiving prepayment

- Warranty: One year or 1, 000 hours from the date of shippment

(15 Months or 1, 200 hours for Alternator Part).



C: Control System:



1, AST (Automatic Start Type Control System), Optional Automatic Start Type System is provided When there is an interruption in the commercial power supply (or there is a start signal in other generator sets), this generator set will, subject to time delay acknowledgement (0-30 S adjustable), be automatically started (1-8 times adjustable). In addition, it is provided with a basic protection function and digital or meter indication of voltage, current, frequency and rotation speed parameters.



2, ATS (Automatic Transfer System), The optional system is provided with a fully automatic transfer switch, a control electric apparatus and an indicator light on the control panel and is coordinated with an automatic type contral cabinet, thus serving the fuction of automatic changeover between the power supplied by the grid and the power generated by the genset.



3, Sync Parallel Control System, this control system can connect 2 or 3 or 4 gensets to make more larger power. such as: if you want 1000kw power, you can choose 2 sets 500kw gensets to work together, using this control system can make 1000kw power.



D: Payment

T/T, 30% deposit, 70% will be payed before delivery

T/T, 30% deposit , 70% L/C at sight

100% L/C at sight



E: Delivery Time:

About 15 days After Receive Your Deposit
