• Ⅰ Technical parameters:

              MAX OD(mm): 73, 88.9

              MM ID(mm): 40, 52

              Overall length (m): 2, 3, 6, 9



               Ⅱ   Specifics:

1. The skeleton welded by lining tube and stainless steel rod and components, which is effective supports for sand filter mesh and not to block liquid, can ensure that the oil enter into the pore canal without any remaining fine sand.


2. Skeleton and sand filter net are all made of stainless steel material in order to improve the corrosion resistance in the corrosive medium, and guarantee the strengthen and extend service life of the skeleton and the sand filter mesh.


3. The inner tube assembly of sand control screen is hanging inside the outer tube and centralize for ensuring the enough annular clearance between the outside sand control pipe and tube to make the sand filter smoothly sink down in the pocket of the tail pipe without any stop.


4. Different length and diameter is designed to against the different condition of the oil well, regarding the fluid production and sand production. You can choose base on your actual needs.
