                                                    HP Push pull tensile tester with test stand

Function & Specification

High accuracy & high resolution

Having 5 kinds of test modes, 3 kinds of display usages for selection

Units : N, Kg and Ibf for your selection, which can make conversion each

Function of reset the acceleration of gravity;

Peak hold function

Peak automatic clearance function;

Set the tolerance limit (Max/Min);

Super memory function - deposit 888 test values

Automatic power off function

With 2 sets of different installation size

LCD screen turn direction function

Inductive background light

RS-232 output



HP-30 Force Gauge

Specifications:

Capacity: 30N

Resolution: 0.001N

Sensor: Sensor inside

Accuracy: ±0.5%

Dimension: 230x66x36mm



Test stand specifications:

Capacity: 500N

Stroke: 70mm

Dimension: 200x160x540mm

Net weight: 12KG



Film peel test fixture 1 set
