O Full capacity range from 25KW to 260KW;
O Low chilled water temperature, Dual temperature settings;
O Famous brand scroll compressor with complete protections;
o Best Cooling + Heating&Hot Water solutions for Hotel, Hospital applications.
O Shell tube heat exchanger; Modular design, max 16 chillers working together.
Product Paramenters
Detail
1.silent design, quiet operation
Efficient and reliable closed scroll compressor, low noise large blade axial flow fan, low noise water pump, reasonable and compact system pipeline design, avoid large vibration and arch generation.
2. reliable operation, high efficiency and energy saving
The fully enclosed scroll compressor has the advantages of long service life, low failure rate and high resistance to liquid strike.The international famous brand high efficiency board exchange not only has superior performance, but also can reduce the operation cost of the unit.Special improved heat exchanger, high efficiency, energy saving, professional design and reliable defrosting system can still normal heating operation in the winter of 10℃.
Multi-stage automatic temperature control system makes the unit start current is small, part of the load performance is superior, and can automatically start and stop according to the load changes, to ensure that the unit always in the most economic state of operation.
3. flexible combination, convenient installation
Each module unit has its own frame structure, refrigeration system, power distribution system, control system and refrigeration system protection function.When one of the module units fails, the normal work of other module units will not be affected.
Each unit can be installed in series and parallel or can be installed and used independently, suitable for different places.It has wide application range and strong spatial flexibility.The number of modules can be combined according to the needs of users, and the energy can be applied to a wide range.
4. complete control.The operation is simple
Unique microcomputer intelligent automatic control and safety protection function, with high and low pressure, loss of pressure, water, lack of phase, overload, underpressure, antifreeze, compressor equipped with temperature control and protection functions, winter intelligent defrost, and can be remote monitoring of circulating water freezing.At the same time, the machine is set with a password for easy management.
The air-cooled condenser makes the maintenance of the unit simple and easy. You do not have to consider the damage caused by bad water quality to the condenser. The unique remote control and fault self-diagnosis function make your use easy and free.
5. The appearance is novel and beautiful
Small shape design for you to save valuable occupation area, the unit adopts "V" or "M" type coil design, high space utilization rate, the unit size is small, and the coil surface air supply is more uniform, effectively improve the air distribution, the unit shape is more smooth.
6. a wide range of application
The unit can be operated in the cold ambient temperature of -26℃ to fully meet the needs of heating in cold areas.Can be widely used the size of the new industrial and civil building air conditioning engineering, such as hotel, apartment, hotel, restaurant, office buildings, shopping malls supermarkets, theaters, stadiums, hospitals and factories and other kinds of buildings, especially the noise and the environment have higher requirements, such as no boiler installation, don't drag cooling towers and other special places, the wind cold (hot) water units is the best choice.
Parameter
Ultra-low ambient temperature heat pump water heater
Remark
Rated working condition (7℃) : When the ambient dry and wet bulb temperature is 7/6℃, the water temperature of the water tank is heated from 9℃ to 55℃.
Note: the parameters of some products have changed in the process of continuous optimization. Please refer to the actual products.
Applications
Widely used in all kinds of large space civil, commercial buildings and industrial plants.(large conference center, gymnasium, exhibition center, large supermarket, movie theater, electronic factory)Especially for places with higher noise requirements or inconvenient indoor installation occasions.Especially suitable for using PWWD series rooftop unit.
