hydro extractor



The dewaterer mainly used for dewatering waste clothes; the dewatering capacity reaches to 350kg ;the whole machine is provided with unique shock--proof,featruing stable operation smooth braking ,high dewatering rate and easy operation  and so on .

 1. The durable shock drum is made of 304 stainless steel;

2. Independent three legs suspended instruction can avoid shock caused by unbalanced loaded and lower noise and make the machine possible to work directly contacted to the ground;

3. Pass through the CE and ISO9001 and ensure quality ;

4. Unique shock-absorber, running stable, smooth braking, high dewatering rate and easy operation



Model		TL-15	TL-25	TL-35	TL-50	TL-70	TL-100	TL-120
Dewatering Capacity(kg)		15	25	35	50	70	100	120
Roller Drum Size(mm)		Φ440×370	Φ570×330	Φ640×330	Φ850×390	Φ950×400	Φ1000×380	Φ1000×380
Dewatering Rotation Speed (r/min)		900	850	830	786	780	770	720
Rated Voltage(V)		220/380	380	380	380	380	380	380
Motor Power(kw)		1.5	1.1	1.5	4	5.5	7.5	11
Dimension(mm)	L	800	1200	1300	1650	1700	1670	2078
	W	800	1000	1100	1300	1400	1460	1548
	H	780	650	750	850	900	1000	1000
Total Weight(kg)		125	350	400	850	900	1000	1200
