Кварцевая высокотемпературная прозрачная кварцевая трубка
US $5.00-$8.00
Кварцевая высокотемпературная прозрачная
- Категория: Quartz Tubes >>>
- Поставщик: Changzhou,Boyan,Optical,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 6.82 $* | 6.42 $* |
| Jul-15-2025 | 5.76 $* | 5.95 $* |
| Jun-15-2025 | 6.51 $* | 6.99 $* |
| May-15-2025 | 6.89 $* | 6.91 $* |
| Apr-15-2025 | 5.85 $* | 5.61 $* |
| Mar-15-2025 | 6.26 $* | 6.66 $* |
| Feb-15-2025 | 6.14 $* | 6.61 $* |
| Jan-15-2025 | 6.93 $* | 6.9 $* |
Характеристики
Product Description
Specification
item | value |
Place of Origin | China |
Jiangsu | |
Brand Name | BOYAN |
Model Number | NA |
Type | Clear Quartz Pipe |
Color | transparent |
Application | Laboratory Test |
Surface Treatment | Polished |
Shape | One End Closed Quartz Tube |
Outside Diameter | 1.5mm~300mm |
Ozone Content | Ozone Free |
Processing Service | Bending, Welding, Punching, Decoiling, Cutting, Moulding |
Product Name | Quartz tube |
Work Temperature | 1250℃ |
Material | 99.99% Pure Quartz |
Color | Clear Transparent |
Soften point | 1730 Degree Celsius |
Density | 2.2g/cm3 |
Usage | Laboratory Test |
Wall Thickness | 0.5 MM-40 MM |
Length | 10-2500mm |
MOQ | 1 Piece |
Physical properties edit broadcast
1, good thermal stability
The thermal expansion coefficient of quartz glass is very small, can withstand drastic temperature changes, the quartz glass is heated to about 1100 ° C, and will not burst into normal temperature water.
2, good light transmission performance
Quartz glass has good light transmission performance in the entire spectral band from ultraviolet to infrared, and the visible light transmittance is more than 93%, especially in the ultraviolet spectral region, the maximum transmittance can reach more than 80%.
3, good electrical insulation performance
The resistance value of quartz glass is equivalent to 10,000 times that of ordinary glass, which is an excellent electrical insulating material and has good insulation properties even at high temperatures.
Because of its excellent physical and chemical properties, quartz glass is widely used in various fields such as electric light source, semiconductor, optical communication, military, metallurgy, building materials, chemistry, machinery, electric power, environmental protection and so on.
4. Disadvantages: fragile.
1, good thermal stability
The thermal expansion coefficient of quartz glass is very small, can withstand drastic temperature changes, the quartz glass is heated to about 1100 ° C, and will not burst into normal temperature water.
2, good light transmission performance
Quartz glass has good light transmission performance in the entire spectral band from ultraviolet to infrared, and the visible light transmittance is more than 93%, especially in the ultraviolet spectral region, the maximum transmittance can reach more than 80%.
3, good electrical insulation performance
The resistance value of quartz glass is equivalent to 10,000 times that of ordinary glass, which is an excellent electrical insulating material and has good insulation properties even at high temperatures.
Because of its excellent physical and chemical properties, quartz glass is widely used in various fields such as electric light source, semiconductor, optical communication, military, metallurgy, building materials, chemistry, machinery, electric power, environmental protection and so on.
4. Disadvantages: fragile.
Density | 2.203g/cm3 |
Hardness | 7(Modified Scale);5.36.5(Mohs Scale) |
Modulus of elasticity | 63·103N·mm-2 |
Poisson's ratio | 0.18 |
Tensile strength | 48.3Mpa |
Compressive strength | ＞1.1Gpa |
Bulk modulus | ~37Gpa |
Rigidity modulus | 31Gpa |
Poisson's ratio | 0.16 |
Coefficient of thermal expansion | 5.5*10- 7cm/（cmK）(from20℃ to 320℃） |
Thermal conductivity | 1.3W/（mK） |
Softening point | 1730℃ |
Annealing point | 1180℃ |
Strain point | 1075℃ |
Electrical resistivity | ＞1018Ωm |
Dielectric constant | 3.75 at 20℃ 1 MHz |
FAQ
Q: What is the shipping option ?
A: We have Fedex and DHL ,SF international shipping for small orders , for bulk orders over 100 kgs ,we prefer air shipping to local airport
Q: How long is your delivery time?
A: Generally it is 3~7 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample ,but we need to take the sample fee .
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
A: We have Fedex and DHL ,SF international shipping for small orders , for bulk orders over 100 kgs ,we prefer air shipping to local airport
Q: How long is your delivery time?
A: Generally it is 3~7 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample ,but we need to take the sample fee .
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
