Завод 60KVA/48KW Perkin s дизельный генератор с алюминиевым навесом
- Категория: Diesel Generators >>>
- Поставщик: GB,Power,Co.,Ltd.,(Shanghai)
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 8806.91 $* | 9246.40 $* |
| Aug-19-2025 | 8732.2 $* | 9169.54 $* |
| Jul-19-2025 | 7326.63 $* | 7692.73 $* |
| Jun-19-2025 | 8584.38 $* | 9013.11 $* |
| May-19-2025 | 7474.52 $* | 7848.27 $* |
| Apr-19-2025 | 8436.70 $* | 8858.55 $* |
| Mar-19-2025 | 8362.80 $* | 8780.69 $* |
| Feb-19-2025 | 8288.98 $* | 8702.59 $* |
| Jan-19-2025 | 8214.87 $* | 8625.4 $* |
Характеристики
VIDEO AND PICTURES
PRODUCT PARAMETERS
Model：GB-P60/S | ||
Prime power | 60KVA/48KW | |
Standby power | 66KVA/52.8KW | |
Engine | 1103A-33TG2 | |
Alternator | TAL-A42-H | |
Controller | DeepSea 6120 | |
Voltage | 440/254V, 415/240V, 400/230V, 380/220V | |
Rated Speed | 1500RPM | |
Engine Configuration | 3Cylinder In Line, 4Stroke,Direct Injection | |
Gas Feeding Model | Turbocharged | |
Bore×Stroke | 105×127(MM) | |
Displacement | 3.3L | |
Speed Governor | Mechanical | |
Starter Model | 12V DC Start | |
Cooling System | Water Cool | |
Compression Ratio | 17.25:1 | |
Fuel Consumption (Prime Power 100%) Load | 13.9L/H | |
Fuel Consumption (Prime Power 75%) Load | 10.4L/H | |
Fuel Tank Capacity | 150L | |
Oil Capacity | 8.3L | |
Oil Consumption | ≤0.15% of Fuel Consumption | |
Excitation Model | Brushless, Self-Exciting | |
Cooling Method | Air Cooling | |
Connection Type | 3 Phase and 12 Wires “Star” Connection | |
Protection Class | IP23 | |
Insulation Class | H | |
Key Fetures | ||
1.CNC Punching MachineThe plates which are less than 3mm can meet the high precision needs of everycomponents after processing by automatic CNC punching machine. | ||
2.Spray Painting LineAutomatic spray painting line ensures the tone unification , spaying evenlyWhat's more ,it can quarantee the elegant appearance and it's endurance. | ||
3.CNC Shear MachineThe 3-15mm plates can satisfy the needs of different products after cuttingby the shearing machine. | ||
4.Laser Cutting MachineThe 3-15mm thick plates can make our products smoother and compacter onstructure after cutting by the laser cutting machine. | ||
5.CNC Bending MachineFull- automatic CNC bending machine can guarantee the accuracy of theproducts' shape. | ||
6.Dry loading testing Equipment2000KW dry loading testing equipment ensures the normal operation in the extremenatural conditions by imitating the extreme working environment(high temperature,high humidity , anoxia) . | ||
7.Tanks and other important components use argon fluorine welding, to ensure materiadeformation and durability. | ||
8. Trial assembly before painting, to ensure accurate product's dimension, to reduce amendmentin the leaving process, and to ensure that the production run smoothly. | ||
9.The product appearance can be kept in the long period, which can resistance brightlight and rain,by using strict phosphoric acid pickling, the outdoor painting, and thestandard power coating paint. | ||
10.Standard unified product testing, which all products adjust and test before leavingfactory, to ensure that the end customers can use directly, and ensure that eachproduct be friendly for end customer. | ||
11.Concise and reasonable packing ensure transfer easily and can help customerstake down conveniently. | ||
12.Technology process decompose, to ensure that the product structure is reasonable. | ||
13.To manage the workshop by 5S can ensure production schedule orderly , and clearness in working site. | ||
14.Strictly control the supply channels, to ensure the high quality raw material be supplied | ||
15.Laser cutting machine, CNC punch press, to ensure the precision of cutting dimension | ||
16.CNC bending machine, to ensure pretty product edge, and appropriate gap | ||
CONTROLLER AND ATS
CANTON FAIR
PROJECT DISPLAY
PRODUCT LINE
TEST PICTURE
INVENTORY SHOW
