Китай вакуумная формовочная машина многофункциональная
- Категория: Plastic Vacuum Forming Machines >>>
- Поставщик: Jinan,Grandio,Cnc,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 3094.2 $* | 3249.65 $* |
| Aug-18-2025 | 3068.79 $* | 3221.8 $* |
| Jul-18-2025 | 2574.4 $* | 2703.32 $* |
| Jun-18-2025 | 3016.68 $* | 3167.61 $* |
| May-18-2025 | 2626.3 $* | 2757.72 $* |
| Apr-18-2025 | 2964.13 $* | 3112.54 $* |
| Mar-18-2025 | 2938.19 $* | 3085.45 $* |
| Feb-18-2025 | 2912.74 $* | 3058.90 $* |
| Jan-18-2025 | 2886.26 $* | 3030.6 $* |
Характеристики
Product Description
Mechanical Features
Acrylic Blister Machine and plastic vacuum forming machine, is making the plasticization of PVC, PE, PP, PET, HIPS and other thermoplastic plastic material into various shapes of advanced packaging boxes. Its compression parts are made of large steel so that it has high strength, good rigidity as well as smooth work surface. The lifting and moving platform adopts high precision four axis guidance, therefore the lifting and moving platform is stable when lifting up and down. Compared with the traditional acrylic forming machine, the water balance system is added on the basis of the original balance rack system so that the balance problem of the lifting form work is solved thoroughly.
Application
Concave and convex Acrylic letters, pictures, light box and scutcheon.
Suitable Materials
Acrylic; ABS, PC, PS, PVC,PP and others .
Operating Principle
Acrylic sheet is heated to be soften, and by the suction effect, it rely on mold closely.
Concave and convex Acrylic letters, pictures, light box and scutcheon.
Suitable Materials
Acrylic; ABS, PC, PS, PVC,PP and others .
Operating Principle
Acrylic sheet is heated to be soften, and by the suction effect, it rely on mold closely.
Specification
Model | GD-1325 |
Overall dimension | 3400 * 2400 * 1700mm |
Plastic Type | PE, PVC, PET, ABS |
Max.Forming Height(mm) | 200mm |
Forming Width (mm) | 1300mm |
Forming Length (mm) | 2500mm |
Internal dimension of fixture | 1300 * 1500mm |
Heating Power (kW) | 15kW |
Production Speed(times/h) | 1200 |
Power Supply | 3 phase 380V50HZ/220V60Hz |
Vacuum pump | 40 m3 / h |
Function | pressure, suction, reverse blow demoulding |
Weight (T) | 1.2T |
Warranty | 1 Year |
Application scope of polishing machine
Button control
Cylinder switchPress cylinder button to open the heating cover
The heater customized by the factory can operate continuously for 24 hours, with a service life of 8000-10000 hours and a working temperature difference of ± 5 degrees, which can ensure the uniform softening temperature of the plate.
The working platform is made of steel with high temperature resistance and long service life. The relative function corresponds to the relative button, and the single-mode molding is adopted, which is easy to operate and reduces the cost of raw materials and labor.
Packaging and Shipping
The wooden box is sealed and packaged for safe transportation and effectively prevent bumps.
Because the machinery is relatively heavy, shipping is generally chosen.
Shipping and payment methods can be negotiated with customer service.
Because the machinery is relatively heavy, shipping is generally chosen.
Shipping and payment methods can be negotiated with customer service.
Company Profile
Jinan Grandio CNC has16 years of production experience, 11 years of export experience, can provide hands-on technical support, has an independent research and development team, can provide continuous product and software upgrade and update services.Qualified after-sales technical teams in many countries, which can help customers solve after-sales problems locally.
Even can help customers who with zero import experience to provide customs clearance to door service.Accept customized and OEM production, with 4 main production workshops, cnc router engraving machines, fiber laser cutting machines, other woodworking machinery, like sanding machine and pvc banding machine...Our new workshop is for 3d scanners,like laser scanner,3d Shining scanner, we provide the highest quality products, low prices and the best service, one-stop shopping, for all customers Free agent purchasing servicealways looking for powerful agent, work together, win-win.
The company's main products include Panel board furniture production line and cabinet door production line:
Standard CNC router(For wood,stone,metal..3axis,4axis and 5axis.support customized,OEM...)
ATC CNC Nesting router,Multi-spindle cnc router machine ,3D scanner,Vacuum membrane press machine,
Wood sanding machine ,Automatic edge banding machine,CNC side hole drilling machine ,Wood CNC lathe ,Fiber laser cutting machine,etc
Even can help customers who with zero import experience to provide customs clearance to door service.Accept customized and OEM production, with 4 main production workshops, cnc router engraving machines, fiber laser cutting machines, other woodworking machinery, like sanding machine and pvc banding machine...Our new workshop is for 3d scanners,like laser scanner,3d Shining scanner, we provide the highest quality products, low prices and the best service, one-stop shopping, for all customers Free agent purchasing servicealways looking for powerful agent, work together, win-win.
The company's main products include Panel board furniture production line and cabinet door production line:
Standard CNC router(For wood,stone,metal..3axis,4axis and 5axis.support customized,OEM...)
ATC CNC Nesting router,Multi-spindle cnc router machine ,3D scanner,Vacuum membrane press machine,
Wood sanding machine ,Automatic edge banding machine,CNC side hole drilling machine ,Wood CNC lathe ,Fiber laser cutting machine,etc
FAQ
1. who are we?
We are based in Shandong, China, start from 2017,sell to Eastern Europe(18.00%),Northern Europe(15.00%),Southeast Asia(10.00%),Southern Europe(10.00%),Eastern Asia(8.00%),South Asia(8.00%),Western Europe(7.00%),North America(6.00%),South America(5.00%),Africa(5.00%),Central America(4.00%),Oceania(2.00%),Mid East(2.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CNC Router,Laser Machine,Vacuum Laminating Machine/Edge Banding Machine/Wood Polishing Machine,Side Hole Drilling Machine
4. why should you buy from us not from other suppliers?
Jinan chuangdiao 3d CNC has16 years of production experience, 11 years of export experience, can provide hands-on technical support, has an independent research and development team, can provide continuous product and software upgrade and update services.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,CNY,CHF;
Accepted Payment Type: T/T,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Shandong, China, start from 2017,sell to Eastern Europe(18.00%),Northern Europe(15.00%),Southeast Asia(10.00%),Southern Europe(10.00%),Eastern Asia(8.00%),South Asia(8.00%),Western Europe(7.00%),North America(6.00%),South America(5.00%),Africa(5.00%),Central America(4.00%),Oceania(2.00%),Mid East(2.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CNC Router,Laser Machine,Vacuum Laminating Machine/Edge Banding Machine/Wood Polishing Machine,Side Hole Drilling Machine
4. why should you buy from us not from other suppliers?
Jinan chuangdiao 3d CNC has16 years of production experience, 11 years of export experience, can provide hands-on technical support, has an independent research and development team, can provide continuous product and software upgrade and update services.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,CNY,CHF;
Accepted Payment Type: T/T,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
