Компрессор EVI R290 DC инвертор A +++
- Категория: Heat Pump Water Heaters >>>
- Поставщик: Foshan,Hetapro,Hvac,Equipment,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.12 $* | 0.76 $* |
| Aug-16-2025 | 0.38 $* | 0.5 $* |
| Jul-16-2025 | 0.21 $* | 0.82 $* |
| Jun-16-2025 | 0.21 $* | 0.73 $* |
| May-16-2025 | 0.75 $* | 0.19 $* |
| Apr-16-2025 | 0.69 $* | 0.2 $* |
| Mar-16-2025 | 0.40 $* | 0.89 $* |
| Feb-16-2025 | 0.96 $* | 0.46 $* |
| Jan-16-2025 | 0.36 $* | 0.34 $* |
Характеристики
Product Description
Specification
Model | / | HEAW10MRN5-A | HEAW16MRN5-A | |||||
Power Supply | V/Ph | 220V/1ph | 220V/1ph | 380V/3ph | ||||
Heating(A7/6℃,W30/35℃) | ||||||||
Heating Capacity | kw | 9.95 | 15.88 | 15.88 | ||||
Power Input | kw | 2.07 | 3.55 | 3.55 | ||||
COP | W/W | 4.81 | 4.47 | 4.47 | ||||
Heating(A7/6℃,W47/55℃) | ||||||||
Heating Capacity | kw | 9.34 | 15.97 | 15.97 | ||||
Power Input | kw | 3.07 | 5.85 | 5.85 | ||||
COP | W/W | 3.04 | 2.73 | 2.73 | ||||
Cooling(A35/24℃,W12/7℃) | ||||||||
Cooling Capacity | kw | 8.20 | 14.00 | 14.00 | ||||
Power Input | kw | 2.52 | 5.19 | 5.19 | ||||
EER | W/W | 3.25 | 2.70 | 2.70 | ||||
ERP Level(35℃) | / | A+++ | A+++ | A+++ | ||||
ERP Level(55℃) | / | A++ | A++ | A++ | ||||
Rated water flow | m3/h | 1.01 | 1.73 | 1.73 | ||||
MAX input power | kw | 5.01 | 7.92 | 7.92 | ||||
MAX input current | A | 19 | 30 | 30 | ||||
Motor type of outdoor unit | / | DC fan | ||||||
Number of fan blades of outdoor unit | / | 1 | ||||||
Compressor | / | Meizhi/Rotary/EVI | ||||||
Water Pump | / | New Territories/Inverter/Built-in | ||||||
Air side heat exchanger | / | Finned tube | ||||||
Water side heat exchanger | Plate type | |||||||
Defrost | / | Auto defrost with 4 way valve | ||||||
Waterproof grade | / | IPX4 | ||||||
Sound power Level3 | dB(A) | 60 | 68 | |||||
Max water outlet temperature | ℃ | 60 | 60 | |||||
Cooling ambient temperature | -5 ~43 | |||||||
Heating ambient temperature | -25 ~ 35 | |||||||
DHW ambient temperature | -25 ~43 | |||||||
Cooling Outlet water temperature | 5 ~ 30 | |||||||
Heating Outlet water temperature | 12 ~ 65 | |||||||
DHW ( tank ) Outlet water temperature | 10 ~ 60 | |||||||
Water side connection | / | R5/4" | ||||||
Unit dimension (W×H×D) | mm | 1325×903×500 | 1325×500×903 | |||||
Packing dimension (W×H×D) | mm | 1410×1055×550 | 1410×1055×550 | |||||
Net | kg | 118 | 130 | |||||
Gross weight | kg | 154 | 166 | |||||
Notes: 1. Relevant EU standards and legislation: EN14511; EN14825; EN50564; EN12102; (EU) No 811/2013; (EU) No 813/2013; OJ 2014/C 207/02. 2. Seasonal space heating energy efficiency class tests in average climate conditions. 3. Sound power test condition ：EN12102- 1 | ||||||||
DHW: Domestic hot water. | ||||||||
item | value |
After-sales Service Provided | Free spare parts, Overseas Call Centers |
Warranty | 2 years |
Application | Outdoor, Hotel, Commercial, Household |
Power Source | Electric |
App-Controlled | Yes |
Private Mold | Yes |
Type | Air to air Heat Pump |
Installation | Freestanding |
Storage / Tankless | Instant / Tankless |
Housing Material | Stainless steel |
Use | Indoor /outdoor |
Place of Origin | China |
Guangdong | |
Brand Name | Heta |
Model Number | HEAW10MSRN3-B |
Function | House Heating Cooling Hot Water |
Refrigerant | R290 |
Compressor | EVI DC Inverter Compressor |
Controller | Color Touch Screen |
Max Hot Water Temperature | 75C |
Water pump | DC Water Pump |
Sound Level | 45 |
OEM Service | Avaliable |
Working Ambient Temperature | Minus 35C-45C |
Power Supply | 220-240/1/50 (V/Ph/Hz)/380-415/3/50(V/Ph/Hz)) |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Company introduction
Foshan Hetapro HVAC Equipment Co., Ltd. is one of the JV partner of Devotion Group.
Devotion Group was established in 1993 and has been working on heating products for over 30 years. It went public in 2003 and had
a total turnover of $400 million in 2022.
Hetapro HVAC is mainly responsible for the production, R&D and sales of heat pump water heaters, modular chillers, and
high-temperature commercial heat pumps. The factory base is located in Huangpu Industrial Zone, Guangzhou, Guangdong, with a
superior geographical location. The factory covers an area of 40000 square meters and consists of four large production workshops,
four heat pump test laboratories, two grant warehouses with loading and unloading platforms.
With the support from Devotion Group, Hetapro heat pump has achieved rapid development in recent years. It has successively
launched the heat pump Thermax series, includes R32 Cooling heating and DHW heat pump with both split and monoblock type, R290
monoblock heat pump with 75℃ hot water ; also the R32 DC inverter swimming pool Poolar series, as well as R32 DC inverter
commercial hot water Commax series and R32 DC inverter modular chiller Vandin series, which have been recognized in the heating
fiel of business globally.
In addition to providing standard products and services, Hetapro HVAC can also offers satisfied OEM/ODM service and high-end
customization services, such as Nordic low-temperature water source, geothermal heat pump series, and ODM projects with well-known
European local heating brands.
Hetapro HVAC has always adhered to the product concept of "low-carbon, high-efficiency, and high-quality", and will be committed
to the world's environmental zero carbon plan, to provide the market and customers with more green, environmentally friendly,
energy-saving, and comfortable HVAC products.
Devotion Group was established in 1993 and has been working on heating products for over 30 years. It went public in 2003 and had
a total turnover of $400 million in 2022.
Hetapro HVAC is mainly responsible for the production, R&D and sales of heat pump water heaters, modular chillers, and
high-temperature commercial heat pumps. The factory base is located in Huangpu Industrial Zone, Guangzhou, Guangdong, with a
superior geographical location. The factory covers an area of 40000 square meters and consists of four large production workshops,
four heat pump test laboratories, two grant warehouses with loading and unloading platforms.
With the support from Devotion Group, Hetapro heat pump has achieved rapid development in recent years. It has successively
launched the heat pump Thermax series, includes R32 Cooling heating and DHW heat pump with both split and monoblock type, R290
monoblock heat pump with 75℃ hot water ; also the R32 DC inverter swimming pool Poolar series, as well as R32 DC inverter
commercial hot water Commax series and R32 DC inverter modular chiller Vandin series, which have been recognized in the heating
fiel of business globally.
In addition to providing standard products and services, Hetapro HVAC can also offers satisfied OEM/ODM service and high-end
customization services, such as Nordic low-temperature water source, geothermal heat pump series, and ODM projects with well-known
European local heating brands.
Hetapro HVAC has always adhered to the product concept of "low-carbon, high-efficiency, and high-quality", and will be committed
to the world's environmental zero carbon plan, to provide the market and customers with more green, environmentally friendly,
energy-saving, and comfortable HVAC products.
Contact us!
Pls feel free to contact us for any request.
FAQ
1. who are we?
We are based in Guang'dong, China, start from 2022,sell to Eastern Europe(45.00%),Western Europe(30.00%),Southern Europe(10.00%),Northern Europe(10.00%),Southeast Asia(5.00%),South Asia(0.00%),Eastern Asia(0.00%),North America(0.00%),South America(0.00%),Oceania(0.00%),Central America(0.00%),Africa(0.00%),Domestic Market(0.00%),Mid East(0.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Heat Pump Water Heater
4. why should you buy from us not from other suppliers?
Hetapro HVAC equipment LTD , as a JV partner with Devotion Group, our mission is to offer green and reliable hot water solutions.
Hetapro has been focusing on heat pump category for 30 years, to offer full range of qualified products to customer globally.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,PayPal;
Language Spoken:English,Chinese
We are based in Guang'dong, China, start from 2022,sell to Eastern Europe(45.00%),Western Europe(30.00%),Southern Europe(10.00%),Northern Europe(10.00%),Southeast Asia(5.00%),South Asia(0.00%),Eastern Asia(0.00%),North America(0.00%),South America(0.00%),Oceania(0.00%),Central America(0.00%),Africa(0.00%),Domestic Market(0.00%),Mid East(0.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Heat Pump Water Heater
4. why should you buy from us not from other suppliers?
Hetapro HVAC equipment LTD , as a JV partner with Devotion Group, our mission is to offer green and reliable hot water solutions.
Hetapro has been focusing on heat pump category for 30 years, to offer full range of qualified products to customer globally.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,PayPal;
Language Spoken:English,Chinese
