Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-15-2025 | 5474.85 $* | 5748.78 $* |
Aug-15-2025 | 5428.31 $* | 5699.61 $* |
Jul-15-2025 | 4554.3 $* | 4782.81 $* |
Jun-15-2025 | 5336.10 $* | 5603.6 $* |
May-15-2025 | 4646.31 $* | 4878.21 $* |
Apr-15-2025 | 5244.80 $* | 5506.82 $* |
Mar-15-2025 | 5198.86 $* | 5458.11 $* |
Feb-15-2025 | 5152.3 $* | 5410.4 $* |
Jan-15-2025 | 5106.93 $* | 5361.12 $* |
Description: | Designed according to GMP standard, widely used for transfer viscous media in the food-processing, cosmetics and pharmaceutical industries |
Construction: | Horizontal Single stage rotor and Stator series(CNC treatment) |
Material: | SS304/SS316L |
Flow range: | 0-130T/H |
Outlet Pressure: | ≤0.2 MPa. |
Speed: | 2800-2900 rpm (Frequency Converter Control can be choose) |
Rotor Type: | teeth |
Teeth space: | 2.2kw 4mm; > 2.2kw 6mm |
Rotor and stator space: | Standard 0.5mm(optional 0.25mm-0.5mm) |
Motor power: | 1.5kw, 2.2kw, 4kw, ...75KW |
Sealing option: | Sanitary single mechanical seal/Dual End Mechanical Seal |
Seal material: | FKM |
Max feeding medium viscosity: | < 3000CPs |
Voltage: | 110-480V, 50hz/ 60hz |
Bearing: | Japanese NSK |
Motor: | Siemens, ABB, LOCAL etc. |
Surface treatment: | Inner polished and Sandblast outside |
Available connection: | Clamp, Union, Flange etc. |
Available standard: | DIN, SMS, 3A, RJT, ISO/IDF |
Operated: | Electric |
Application scope: | Dairy, food, beverage, pharmacy, cosmetic, etc |
Packaging Details: | Plywood case Or as per the request of customers |
Bailishi High-Speed Shearing emulsification pump is a new product researched and developed by our company after assimilating foreign advanced techniques and processes.
Its various indicators can reach the domestic advanced level and quality can meet GMP technical requirements for IS09001 certified products.
It is especially suitable to emulsification homogeneous machine of essential mixed liquor for re-provision, drinking, chemical engineering, biochemistry, pigment, dye, coating and pharmacy, etc.
The biggest characteristic is omni-bearing function of high-speed shearing, dispersion, homogenized milk, homogeneity, mixing, crushing and conveying without adopting grinding media in the production process.
1.Large volume treatment, suitable for industrialized online continuous production;
2.The distribution range is narrow with high homogenization;
3.Energy saving, time saving, high efficiency;
4.Low noise, steady operation;
5.Eliminates the difference between different lots;
6.No blind angle, the material will be separated and cut 100;
7.With shod distance, low ift transmission function;
8.Easy to operate and maintain;
9.Automatic control can be realized.
Model | Power kw | Speed rpm | Flow m3/h |
BRL1-60 | 1.5 | 2800 | 0-0.15 |
BRL1-100 | 2.2 | 2800 | 0-3 |
BRL1-130 | 4 | 2800 | 0-4 |
BRL1-140 | 5.5 | 2800 | 0-5 |
BRL1-165 | 7.5 | 2800 | 0-8 |
BRL1-180 | 11 | 2800 | 0-12 |
BRL1-185 | 15 | 2800 | 0-18 |
BRL1-200 | 22 | 2800 | 0-25 |
BRL1-210 | 30 | 2800 | 0-35 |
BRL1-230 | 45 | 2800 | 0-50 |
BRL1-245 | 55 | 2800 | 0-75 |
BRL1-260 | 75 | 2800 | 0-90 |
BRL1-275 | 90 | 2800 | 0-110 |
BRL1-280 | 132 | 2800 | 0-130 |
1. Food industry:
Chilli sauce, sesame, fruit tea, ice cream, cream, jam, fruit juice, soybean, soybean paste, sweetened bean paste, peanut milk, SoyaMax, soymilk, dairy product, malted milk, essence, condiment and various eatables, etc;
2. Chemical industry:
Paint, pigment, dye, coating, lubrication oil, Octyldodecyl Neopentanoate, lubrication grease, diesel oil, petrochemical catalyst, emulsified asphalt, modified asphalt, paraffin, cementing agent, detergent, plastics, dynamite, glass fiber reinforced plastics, synthetic leather, resin, plastics, leather and emulsion explosive, etc;
3. Commodity chemicals:
Toothpaste, detergent, cream, lipstick, mildy wash, shampoo, shoe polish, senior cosmetics, shower gel, soap, coagulant, spice and balsam, etc;
4. Pharmaceutics: Various syrups, nutrient solutions, Chinese patent drugs, poultices, biological agents, cod-liver oil, pollens, royal jelly, vaccines, ointments, oral liquids, bactericides, injection, antibiotics,microcapsules and dropping liquid infusion, etc;
5. Building industry:
Various coatings including inner and outer wall coating, anti-corrosive and waterproof coating, ceramic coating, multicolor finish, ceramic glaze, nano-coating and spraying, etc;
6. Paper manufacturing industry:
Paper pulp, cementing agent, rosin emulsifying agent, paper making additive and resin emulsion product, etc;
7. Pesticide industry:
Bactericide, seed coating formulations, herbicide, emulsifiable concentrates of pesticides, chemical fertilizer, biochemistry pesticide and biopesticide, etc;
8. Other industries:
Textile industry, null coal floating agent, rare earth, dispersion and depolymerization of nano materials, abstraction reaction and water industry, etc;
Quality stainless steel
Contact parts of machine are completely made of food grade stainless steel 304/316L, meeting the standard of GMP.
Construction: \t
Horizontal Single stage rotor and Stator series(CNC treatment)
Available pump inlet and outlet port connection:\t
standard Clamp, optional Union, Flange etc.
Drain port
clamped, connected with butterfly valve
Pure copper motor:
1)low noise, stable dynamic, sustainable work.
2)with waterproof motor cover
3) The anti-pound coating and the water tray structure of the fuselage improve the safety of the motor, and the motor directly
drives the grinding head to rotate, which saves time.
Sealing option:\t
Sanitary Dual End Mechanical Seal
Cooling water port for sealing cooling
Rotor Type:\tteeth
Teeth space:\t2.2kw 4mm; > 2.2kw 6mm
Rotor and stator space:\tStandard 0.5mm(optional 0.25mm-0.5mm)
a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.
We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).
We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.
Please contact our After-sales service department in time within 30days after you received the cargo. | ||
Tel: 86-577-86821328 Time: 9:00 a.m.- 6:00 p.m. (Beijing time) | ||
Process | Please provide the copy of Sales Contract and describe the problems appeared. | |
Problems confrimation: | ||
Slight problem: | Please send the proof to our After-Sales Department, we will reply within two days. | |
Serious problem: | ||
a | We will dispatch our Quality and Problems Appraisers to make a confirmation. | |
b | Have a negotiation of the compensation and sign agreements | |
c | Our After-Sales Department will perform the duties as the agreements |
