Hoymiles Hm 1500 Wechselrichter Hm-1200 Hm-800 Hm-1500
- Категория: Solar Energy Products >>>
- Поставщик: Yichun,Dawnice,Manufacture,&,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 164.29 $* | 167.90 $* |
| Jul-18-2025 | 133.50 $* | 136.14 $* |
| Jun-18-2025 | 161.9 $* | 164.96 $* |
| May-18-2025 | 160.27 $* | 163.0 $* |
| Apr-18-2025 | 128.35 $* | 131.98 $* |
| Mar-18-2025 | 157.84 $* | 160.53 $* |
| Feb-18-2025 | 156.82 $* | 159.85 $* |
| Jan-18-2025 | 155.87 $* | 158.67 $* |
Характеристики
Product Description
* Single microinverter connects four PV modules with dual MPPT
* Peak output power up to 300/600/800W; Adapted to 60 & 72 cells PV panels
* Peak efficiency 95.70%; CEC weighted efficiency 95.50%
* Static MPPT efficiency 99.80%; Dynamic MPPT efficiency 99.76% in overcast weather
* High reliability: NEMA6 (IP67) enclosure; 6000V surge protection
* Peak output power up to 300/600/800W; Adapted to 60 & 72 cells PV panels
* Peak efficiency 95.70%; CEC weighted efficiency 95.50%
* Static MPPT efficiency 99.80%; Dynamic MPPT efficiency 99.76% in overcast weather
* High reliability: NEMA6 (IP67) enclosure; 6000V surge protection
1.In microinverter system the solar panels are connected in parallel, without high voltage on the DC side, which has a good
safety.
2.The solar panels do not interfere with each other, independent power generation has no short-board effect.The system efficiency can be maximized.
3.In the environment with shadow obscuration,it can shows more efficient conversion efficiency than ordinary on grid string inverters.
4.In the same system, it can be flexibly designed to connect to different power and different types of solar panels.
5.The background can monitor the power generation of each solar panels to reduce maintenance costs.
6.The design service life is 25 years, and the comprehensive investment cost is lower.
safety.
2.The solar panels do not interfere with each other, independent power generation has no short-board effect.The system efficiency can be maximized.
3.In the environment with shadow obscuration,it can shows more efficient conversion efficiency than ordinary on grid string inverters.
4.In the same system, it can be flexibly designed to connect to different power and different types of solar panels.
5.The background can monitor the power generation of each solar panels to reduce maintenance costs.
6.The design service life is 25 years, and the comprehensive investment cost is lower.
Model | HM-1200 | HM-1500 | ||||
Input Data (DC) | ||||||
Commonly used module power (W) | 240 to 405+ | 300–505+ | ||||
Maximum input voltage (V) | 60 | |||||
MPPT voltage range (V) | 16–60 | |||||
Start-up voltage (V) | 22 | |||||
Maximum input current (A) | 4 × 11.5 | |||||
Maximum input short circuit current (A) | 4 × 15 | |||||
Number of MPPTs | 2 | |||||
Number of inputs per MPPT | 2 | |||||
Output Data (AC) | ||||||
Rated output power (VA) | 1200 | 1500 | ||||
Rated output current (A) | 5.22 | 6.52 | ||||
Nominal output voltage/range (V) | 230/180-275 | |||||
Nominal frequency/range (Hz) | 50/45–55 | |||||
Power factor (adjustable) | > 0.99 default 0.8 leading…0.8 lagging | |||||
Total harmonic distortion | < 3% | |||||
Maximum units per branch | 4 | 3 | ||||
Efficiency | ||||||
CEC peak efficiency | 96.70% | |||||
CEC weighted efficiency | 96.50% | |||||
Nominal MPPT efficiency | 99.80% | |||||
Nighttime power consumption(mW) | < 50 | |||||
Mechanical Data | ||||||
Ambient temperature range (°C) | -40 to +65 | |||||
Dimensions (W × H × D mm) | 280 × 176 × 33 | |||||
Weight (kg) | 3.75 | |||||
Enclosure rating | Outdoor IP67 (NEMA 6) | |||||
Cooling | Natural convection (no fans) | |||||
Features | ||||||
Communication | 2.4 GHz Proprietary RF (Nordic) | |||||
Type of isolation | Galvanically Isolated HF Transformer | |||||
Monitoring | S-Miles Cloud | |||||
Compliance | VDE-AR-N 4105: 2018, EN 50549-1: 2019, VFR 2019, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3 | |||||
