В наличии регулятор 6 Вт ~ 250 370 однофазный 110 В/220 простой контроллер нормальной скорости для электродвигателя
- Категория: Motor Controllers >>>
- Поставщик: Zhejiang,Xingli,Import,And,Export,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 7.10 $* | 7.53 $* |
| Aug-19-2025 | 7.83 $* | 7.36 $* |
| Jul-19-2025 | 6.34 $* | 6.60 $* |
| Jun-19-2025 | 7.48 $* | 7.30 $* |
| May-19-2025 | 6.69 $* | 6.36 $* |
| Apr-19-2025 | 7.79 $* | 7.16 $* |
| Mar-19-2025 | 7.52 $* | 7.43 $* |
| Feb-19-2025 | 7.64 $* | 7.35 $* |
| Jan-19-2025 | 7.61 $* | 7.86 $* |
Характеристики
Product Description
Model performance parameter table | ||||||||
Applicable motor power | 6W 15W 25W 40W 60W 90W 120W 140W 150W 200W 250W 300W 400W | |||||||
Motor type used | Speed Control motor | |||||||
Installation method | Panel type | |||||||
Speed mode | Panel potentiometer | |||||||
Running capacitor | Built-in (built into the speed controller) | |||||||
Speed range | 50Hz:120-1350r/min;60Hz:120-1680r/min | |||||||
Power frequency | 50Hz 60Hz | |||||||
Use environment | -10°C-+45°C(nofreezing),below85%(no condensation) | |||||||
MOTOR FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | |
MOTOR TYPE | INDUCTION MOTOR / REVERSIBLE MOTOR / TORQUE MOTOR / SPEED CONTROL MOTOR | |
OUTPUT POWER | 3W / 6W / 10W / 15W / 25W / 40W / 60W / 90W / 120W / 140W / 180W / 200W (Can be customized) | |
OUTPUT SHAFT | 8mm / 10mm / 12mm / 15mm Round shaft, D-cut shaft, key way shaft (Can be customized) | |
VOLTAGE TYPE | 110V,120V,220V,230V,380V,400V,415V | |
FREQUENCY | 50Hz/60Hz Single Phase/ Three Phase | |
ACCESSORIES | Terminal box / Fan / Thermal protector / Electric magnetic brake / Controller | |
GEARBOX FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | |
GEAR RATIO | MINIMUM 3:1---------------MAXIMUM 750:1 | |
GEARBOX TYPE | Parallel shaft gearbox / Strength type gear box | |
Right angle hollow /solid / L type worm shaft | ||
*Power/Shaft size/Mounting Flange can be customized according to your requirements | ||
