Рыночная заводская цена тепловой насос 11 48

Описание и отзывы

Трекер стоимости

Характеристики

Model				heatpump	FAC-04-1
Unit functions	Rated heating	Heating capacity		kW	11.48
				Btu/h	39181
		Rated power		kW	3.53
		Rated current		A	14.5
	Rated cooling	Cooling capacity		kW	9.74
				Btu/h	33242
		Rated power		kW	3.34
		Rated current		A	14.8
	Max ruuning current			A	21.5
	Power			V/Ph/Hz	220V~240/1N/50Hz  380V~415/3N/50Hz/60HZ
	Noise			dB(A)	46
	Size		L(A)	mm	1430
			w(B)	mm	460
			H(C)	mm	830
	Weight			kg	135
Operating control	Precision temp precision			℃	±1℃
	Operation range			℃	—20℃~45℃
	Operation panel	Type			LCD
		Main functions			Operating mode,temperature,operating condition, timing
Throttling					Electronic expansion valves
The  outlet temp				℃	60℃
Refrigerate	Type				R410A, R32
Compressor	Type				Scroll Copeland, panasonic,
	Qty			Pc	1
Air side heat exchange	Type				Finned heat exchange
	Qty			pc	1
	Fan type			Type	Axial big twist angle fan
	Motor power			w	50
Water side heat exchange	Type				tube in shell heat exchanger
	Water flow(summer)			m3/h	1.45
	Water flow(winter)			m3/h	1.79
	Water pressure down			kpa	29
	Connection dimension			Inch	1
	Water side max working pressure			KPA	1000
Circulate water pump					No
water flow switch					Yes
(FOB GUANGZHOU)				USD	1068
