Пластиковая 3-в-1 гранулирующая система Erema уплотнительный резак HDPE LDPE LLDPE линия
- Категория: Plastic Granulators >>>
- Поставщик: Suzhou,Deedo,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 47362.92 $* | 49730.61 $* |
| Aug-16-2025 | 46964.81 $* | 49312.6 $* |
| Jul-16-2025 | 39402.87 $* | 41372.79 $* |
| Jun-16-2025 | 46168.10 $* | 48476.36 $* |
| May-16-2025 | 40198.41 $* | 42208.96 $* |
| Apr-16-2025 | 45372.6 $* | 47641.20 $* |
| Mar-16-2025 | 44974.71 $* | 47223.37 $* |
| Feb-16-2025 | 44576.68 $* | 46805.47 $* |
| Jan-16-2025 | 44178.98 $* | 46387.71 $* |
Характеристики
Product Description
Pelletizer for Granule Productions/Plastic Extruder
Granulator can be used in the process of various plastic granulation particles, which can be used for PP,PE,PS,ABS,OPPand other
plastics to granulate. For several characteristics and advantages of granulator, it is particularly remarkable in the following
places:
1) The screw part is carefully developed and designed, the whole machine and each part are equipped reasonably, and all the lines
are heated by three fires and one zero.
2) The screw is designed according to the characteristics of the material, so the granulator has high efficiency and speed, the
products produced have strong gloss, the particle size is full, the configuration of the whole machine is increased, and the
service life of the equipment is added. In the appearance aspect has also carried on the rationalization design, therefore has the
unique aesthetic feeling.
3) This granulator adopts reasonable design, the production volume has also been greatly improved, the finished product
performance-price ratio is higher, the maintenance time is reduced, so the maintenance cost of users is also reduced.
4) The characteristics of high output and low energy consumption are equipped with large torque reducer and motor, and the screw
is specially designed and processed. No dead angle, no iron jam, effectively improve the production capacity, enhance the plastic
plastic effect. Equipped with single exhaust double exhaust structure, full drainage, exhaust, so that the particles are more
strong and full.
5) High quality electrical and driving equipment to make the granulator more safe and reliable in the process of use.
Granulator can be used in the process of various plastic granulation particles, which can be used for PP,PE,PS,ABS,OPPand other
plastics to granulate. For several characteristics and advantages of granulator, it is particularly remarkable in the following
places:
1) The screw part is carefully developed and designed, the whole machine and each part are equipped reasonably, and all the lines
are heated by three fires and one zero.
2) The screw is designed according to the characteristics of the material, so the granulator has high efficiency and speed, the
products produced have strong gloss, the particle size is full, the configuration of the whole machine is increased, and the
service life of the equipment is added. In the appearance aspect has also carried on the rationalization design, therefore has the
unique aesthetic feeling.
3) This granulator adopts reasonable design, the production volume has also been greatly improved, the finished product
performance-price ratio is higher, the maintenance time is reduced, so the maintenance cost of users is also reduced.
4) The characteristics of high output and low energy consumption are equipped with large torque reducer and motor, and the screw
is specially designed and processed. No dead angle, no iron jam, effectively improve the production capacity, enhance the plastic
plastic effect. Equipped with single exhaust double exhaust structure, full drainage, exhaust, so that the particles are more
strong and full.
5) High quality electrical and driving equipment to make the granulator more safe and reliable in the process of use.
Details Images
Production Processing
Main Features:
1. Feeding way of plastic pelletizing recycling plant: Special designed force feeder, side feeder and compactor can push the material into the extruder high efficiently. Guarantee getting good capacity of the machine
2. Gear reducer of plastic pelletizing recycling plant: The high torque, hard-surface gear reducer with water cooling circulation system ensures the line running steady, silent, and long life.
3. Barrel and screw of plastic pelletizing recycling plant: The special material (38CrMoA1A & double alloy) and hardness treatment of the screw and barrel make extruder to be good wear resistance.
4. Degassing of plastic pelletizing recycling plant: Special design for the venting can discharge the moisture and waste air
efficiently which ensure the finally plastic granules are with smooth surface, no water, no bubble, and good quality.
5. Hydraulic filter of plastic pelletizing recycling plant: Double position hydraulic filter works swift and easy to operate.
Copper ring prevents the material leakage.
6. Cutting way of plastic pelletizing recycling plant: Two type cutting way, the noodle type and water ring type makes the
customer freely to choose.
7. Special designed die of plastic pelletizing recycling plant: All die holes size are special designed due to the material
characters and our rich experience to make machines.
8. Cooling way of plastic pelletizing recycling plant: Most of the materials are cooled by water. Some like PVC are cooled by wind. e with smooth surface, no water, no bubble, and good quality.
9. Cutting way of plastic pelletizing recycling plant: pineapple cutter is for the noodle cutting way, and die face cutter for the water ring cutting way.
10. Package of the final products of plastic pelletizing recycling plant: Final products granules will be blowing into silo, which will be packaged by manual or packaging scale machine
11. Electric parts of plastic pelletizing recycling plant: Siemens, Schneider, Fuji, ABB, Mitsubishi, TECO all electric parts
customized..
1. Feeding way of plastic pelletizing recycling plant: Special designed force feeder, side feeder and compactor can push the material into the extruder high efficiently. Guarantee getting good capacity of the machine
2. Gear reducer of plastic pelletizing recycling plant: The high torque, hard-surface gear reducer with water cooling circulation system ensures the line running steady, silent, and long life.
3. Barrel and screw of plastic pelletizing recycling plant: The special material (38CrMoA1A & double alloy) and hardness treatment of the screw and barrel make extruder to be good wear resistance.
4. Degassing of plastic pelletizing recycling plant: Special design for the venting can discharge the moisture and waste air
efficiently which ensure the finally plastic granules are with smooth surface, no water, no bubble, and good quality.
5. Hydraulic filter of plastic pelletizing recycling plant: Double position hydraulic filter works swift and easy to operate.
Copper ring prevents the material leakage.
6. Cutting way of plastic pelletizing recycling plant: Two type cutting way, the noodle type and water ring type makes the
customer freely to choose.
7. Special designed die of plastic pelletizing recycling plant: All die holes size are special designed due to the material
characters and our rich experience to make machines.
8. Cooling way of plastic pelletizing recycling plant: Most of the materials are cooled by water. Some like PVC are cooled by wind. e with smooth surface, no water, no bubble, and good quality.
9. Cutting way of plastic pelletizing recycling plant: pineapple cutter is for the noodle cutting way, and die face cutter for the water ring cutting way.
10. Package of the final products of plastic pelletizing recycling plant: Final products granules will be blowing into silo, which will be packaged by manual or packaging scale machine
11. Electric parts of plastic pelletizing recycling plant: Siemens, Schneider, Fuji, ABB, Mitsubishi, TECO all electric parts
customized..
Specification
Model | Diameter of screw | PE capacity | PP capacity |
DDJ-85 | Φ85mm | 150-200kg/h | 150-200kg/h |
DDSJ-85/85 | Φ85/85mm | 150-200kg/h | 150-200kg/h |
DDJ-100 | Φ100mm | 280-350kg/h | 250-300kg/h |
DDSJ-100/100 | Φ100/100mm | 280-350kg/h | 250-300kg/h |
DDJ-130 | Φ130mm | 480-550kg/h | 400-500kg/h |
DDSJ-130/130 | Φ130/130mm | 480-550kg/h | 400-500kg/h |
DDJ-160 | Φ160mm | 650-800kg/h | 600-750kg/h |
DDSJ-160/160 | Φ160/160mm | 650-800kg/h | 600-750kg/h |
DDJ-180 | Φ180mm | 800-1200kg/h | 750-1000kg/h |
DDSJ-180/180 | Φ180/180mm | 800-1200kg/h | 750-1000kg/h |
The plastic recycling granulator for the rigid hard material
Advantage:
1.Belt feeding,frequency conversion control. Can be equipped with metal detector.
2.The pot body is equipped with a guide plate for convenient feeding. Improved knife plate and fixed knife,to promote the speed and effect of the granule.
3.Special design can control the temperature of the material inside the compacting-machine pot,so as to improve the granulation efficiency.
Model | Diameter of screw | PE capacity | PP capacity |
TCDJ-65 | Φ65mm | 80-130kg/h | 70-120kg/h |
TCDJ-80 | Φ80 | 100-160kg/h | 80-130kg/h |
TCDJ80/80 | Φ80 | 100-160kg/h | 80-130kg/h |
TCDJ-90 | Φ90 | 130-220kg/h | 130-220kg/h |
TCDJ-90/90 | Φ90 | 130-220kg/h | 130-220kg/h |
TCDJ-100 | Φ100mm | 180-270KG/h | 160-250kg/h |
TCSJ-100/100 | Φ100/100mm | 180-270KG/h | 160-250KG/h |
TCDJ-120 | Φ120mm | 250-370kg/h | 220-350kg/h |
TCSJ-120/120 | Φ120/120mm | 250-370kg/h | 220-350kg/h |
TCDJ-150 | Φ150mm | 350-550kg/h | 320-500kg/h |
TCSJ-150/150 | Φ150/150mm | 350-550kg/h | 320-500kg/h |
TCDJ-180 | Φ180mm | 600-850kg/h | 550-750kg/h |
TCSJ-180/180 | Φ180/180mm | 600-850kg/h | 550-750kg/h |
TCDJ-200 | Φ200mm | 800-1000kg/h | 700-950kg/h |
TCSJ-200/200 | Φ200mm | 800-1000kh/h | 700-950kh/h |
PET double-screw granulator machine
Description of Recycled PET Plastic Granulator Machine
Twin screw extruder recycling & pelletizing system are applied to the waste materials, which needs high processing performance of melting, volatilization, filtering etc., mainly works for the job of PET scraps recycling and re-pelletizing.
Twin screw extruder recycling & pelletizing system are applied to the waste materials, which needs high processing performance of melting, volatilization, filtering etc., mainly works for the job of PET scraps recycling and re-pelletizing.
To slowing down IV reducing during PET flakes/scraps recycling, not only impurities, such as PVC content, moisture, etc., but also precise recycling system and reliable equipment configurations are necessary to put in the solution.
PET plastic pelletizing machine with international advanced recycling technology and combined with the actual application condition. This PET plastic pelletizing machine is design specializes for recycling the recycled washed plastic PET plastic flakes/scraps, such as Cola plastic bottle flakes/scraps, purified water bottle flakes/scraps, PET sheet flakes/scraps, PET drinking bottle flakes/scraps etc.
After processing techniques such as feeding, heating, melt, cooling, drying, cutting etc., the final products are PET plastic pellets/granules that can be to produce new PET plastic products.
Features of Recycled PET Plastic Granulator Machine
The screw is made of high tool steel 38 CrMoALA or W6Mo5Cr4V2. Special screw combination Euro-style rectangle barrel, reflux refrigeration channel optimized and disposed, which makes temperature difference in D areas smaller.
Innovated design of heater-tightened style insures high efficiency of heat transfer and high longevity of heater.
The material is used high quality nitride steel, corrosion proof or antifriction with corresponding processed special designed two sets of vacuum.
New-style project of parallel three-axis driving makes the convex axis, convey Chain, decelerate and torque get together, which keep it compact, and the key bearings are imported soakage and spraying lubrication integrate smoothly technics, strengthening of tooth face, so they can ensure high torque, high precision and low noise
The selected material of drive components is dainty, including super intention alloy, cementiteing steel, cementiting and grinding.
Working Flow of Recycled PET Plastic Granulator Machine
Screw feeder → Parrallel Twin Screw Efficient extruder → Non-stop hydraulic screen filter changer → Water cooling → Strand cutting→ Blower → Storage hopper → Electric control panel
1. Screw feeder: the first step of the pelletizing recycling machine, PET plastic flakes/scraps conveyed into the hopper through screw, the screw connect sensor to detect the material in hopper, once the flakes are full in hopper, the screw will stop; and once empty, the screw feeder will begin working.
2. Extruder: to plasticization and degassing, a specialized single screw extruder applied to melt the pre-compacted material. The plastic scraps will well melted, plasticized in the first stage extruder, and the plastic will be extrude by the second stage extruder. With double-zone vacuum degassing system, volatiles such as low molecular and moisture will be removed efficiency,especially suitable to heavy printed film and material with some water content.
3. Non-stop hydraulic screen filter changer: double stage filtering, fore filtering in the first extruder, and fine filtering in
the second extruder, to reduce the frequency of filtering sieves changing. The requirements on the filter technology depend heavily on the quality of the input material as well as the planned use of granules.
4. Water cooling: made of 304 stainless steel, 4 meters length that fill with water, too cooling the melted plastic.
5. Cutting pelletizing: supplied with speed steel and hard alloy steel cutting blades for reliable performance. Compact structure allows less maintenance.
PET plastic pelletizing machine with international advanced recycling technology and combined with the actual application condition. This PET plastic pelletizing machine is design specializes for recycling the recycled washed plastic PET plastic flakes/scraps, such as Cola plastic bottle flakes/scraps, purified water bottle flakes/scraps, PET sheet flakes/scraps, PET drinking bottle flakes/scraps etc.
After processing techniques such as feeding, heating, melt, cooling, drying, cutting etc., the final products are PET plastic pellets/granules that can be to produce new PET plastic products.
Features of Recycled PET Plastic Granulator Machine
The screw is made of high tool steel 38 CrMoALA or W6Mo5Cr4V2. Special screw combination Euro-style rectangle barrel, reflux refrigeration channel optimized and disposed, which makes temperature difference in D areas smaller.
Innovated design of heater-tightened style insures high efficiency of heat transfer and high longevity of heater.
The material is used high quality nitride steel, corrosion proof or antifriction with corresponding processed special designed two sets of vacuum.
New-style project of parallel three-axis driving makes the convex axis, convey Chain, decelerate and torque get together, which keep it compact, and the key bearings are imported soakage and spraying lubrication integrate smoothly technics, strengthening of tooth face, so they can ensure high torque, high precision and low noise
The selected material of drive components is dainty, including super intention alloy, cementiteing steel, cementiting and grinding.
Working Flow of Recycled PET Plastic Granulator Machine
Screw feeder → Parrallel Twin Screw Efficient extruder → Non-stop hydraulic screen filter changer → Water cooling → Strand cutting→ Blower → Storage hopper → Electric control panel
1. Screw feeder: the first step of the pelletizing recycling machine, PET plastic flakes/scraps conveyed into the hopper through screw, the screw connect sensor to detect the material in hopper, once the flakes are full in hopper, the screw will stop; and once empty, the screw feeder will begin working.
2. Extruder: to plasticization and degassing, a specialized single screw extruder applied to melt the pre-compacted material. The plastic scraps will well melted, plasticized in the first stage extruder, and the plastic will be extrude by the second stage extruder. With double-zone vacuum degassing system, volatiles such as low molecular and moisture will be removed efficiency,especially suitable to heavy printed film and material with some water content.
3. Non-stop hydraulic screen filter changer: double stage filtering, fore filtering in the first extruder, and fine filtering in
the second extruder, to reduce the frequency of filtering sieves changing. The requirements on the filter technology depend heavily on the quality of the input material as well as the planned use of granules.
4. Water cooling: made of 304 stainless steel, 4 meters length that fill with water, too cooling the melted plastic.
5. Cutting pelletizing: supplied with speed steel and hard alloy steel cutting blades for reliable performance. Compact structure allows less maintenance.
Model | Diameter | L/D | Screw rotary | Motor Power | Torque | Capacity |
DTSE-40B | 40mm | 32-52 | 600r/min | 30kw | 239 | 90-150kg/h |
DTSE-52B | 52mm | 32-56 | 600r/min | 55kw | 438 | 225-300kg/ |
DTSE-65B | 65mm | 32-60 | 600r/min | 90kw | 716 | 200-300kg/h |
DTSE-75B | 75mm | 32-64 | 600r/min | 132kw | 1050 | 300-600kg/h |
DTSE-95B | 95mm | 32-64 | 600r/min | 250kw | 2387 | 800-1200kg/h |
Packing & Delivery
Certifications
Exhibition
FAQ
YOU MIGHT INSTERESTED IN FOLLOWING QUESTIONS
2. How do you assistant to install the machine on worksite?
We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation,
commissioning.
3. How can I get spare parts for replacement in other countries?
Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.
4. Can I use mark machine with different LOGO and color?
Yes, please confirm details with sales.
5. Can your customers test the machines?
Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
If you have any need ,pls feel free to contact with us.
1. Are you manufacturer or trading company?
We are a professional recycling machines manufacturer for more than 15years we supplying full technical support and solutions,timely and professional service, always effort on quality, honest, win-win business for every client.
We are a professional recycling machines manufacturer for more than 15years we supplying full technical support and solutions,timely and professional service, always effort on quality, honest, win-win business for every client.
2. How do you assistant to install the machine on worksite?
We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation,
commissioning.
3. How can I get spare parts for replacement in other countries?
Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.
4. Can I use mark machine with different LOGO and color?
Yes, please confirm details with sales.
5. Can your customers test the machines?
Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
If you have any need ,pls feel free to contact with us.
