Характеристики









Product Specification




ZG450 Crawler Water Well Drilling Rig Specification
The weight (T)
9.4
Drill pipe diameter (mm)
Φ89 Φ102
The hole diameter (mm）
140-350
Drill pipe length (m)
1.5m 2.0m 3.0m 6.0m
Drilling depth (m)
450
Rig lifting force (T)
25
One-time advance length (m)
6.6
Rapid rise speed (m/min)
20
Walking speed (km/h)
2.5
Fast feeding speed (m/min)
40
Climbing angles (Max.）
30
Width of loading (m)
2.8
Equipped capacitor (kw)
103
Hoisting force of winch (T)
2
Using air pressure (MPA)
1.7-3.5
Swing torque (N.m)
7000-9500
Air consumption (m3/min)
17-36
Dimension (mm)
5950×2100×2600
Swing speed (rpm)
50-135
Equipped with hammer
Medium and high wind pressure series
The penetration efficiency (m/h)
15-35
High leg stroke (m)
1.6
The engine brand
Weichai engine ( National III )




Item
ZG180
ZGX200
ZG260
ZG280
Drilling Depth(m)
180
200
260
280
Drilling Diameter(mm)
Φ140-254
Φ140-254
Φ140-305
Φ140-305
One-Time Advance Length(m)
3.3
3.3
3.3
6.6
Walking Speed(km/h)
2.5
2.5
2.5
2.5
Climbing Angles(°)
30
30
30
30
Engine & Power(kw)
60
65
70
75
Air Consumption(m3/min)
17-31
17-31
17-31
17-31
Drill Pipe Length(m)
1.5/2.0/3.0
1.5/2.0/3.0
1.5/2.0/3.0
1.5/2.0/3.0
Drill Pipe Diameter(mm)
Φ76 Φ89
Φ76 Φ89
Φ76 Φ89
Φ76 Φ89
Rig Lifting Force(T)
12
13
15
17
Swing speed(rpm)
45-70
45-70
45-70
40-70
Swing torque(N.m)
3200-4600
3400-4700
4000-5300
4500-6000
Dimensions(mm)
4000*1630*2250
3950*1750*2250
4000*1850*2300
5900*1850*2360
Weight(kg)
5200
5000
6500
7600




Item
ZG300
ZGX350
ZG380
ZG450
Drilling Depth(m)
300
350
380
450
Drilling Diameter(mm)
Φ140-325
Φ140-325
Φ140-325
Φ140-350
One-Time Advance Length(m)
3.3/4.8
6.6
6.6
6.6
Walking Speed(km/h)
2.5
2.5
2.5
2.5
Climbing Angles(°)
30
30
30
30
Engine & Power(kw)
85
92
96
103
Air Consumption(m3/min)
17-36
17-36
17-36
17-36
Drill Pipe Length(m)
1.5/2.0/3.0
1.5/2.0/3.0/6.0
1.5/2.0/3.0/6.0
1.5/2.0/3.0/6.0
Drill Pipe Diameter(mm)
Φ76 Φ89 Φ102
Φ89 Φ102
Φ89 Φ102
Φ89 Φ102
Rig Lifting Force(T)
18
22
24
25
Swing speed(rpm)
40-70
66-135
66-135
50-135
Swing torque(N.m)
5700-7500
6200-8500
6500-9000
7000-9500
Dimensions(mm)
4100*2000*2500
6000*2000*2550
5950*2100*2550
5900*1850*2360
Weight(kg)
7200
8600
9200
9400




Item
ZG500
ZGX580
ZG680
ZG800
Drilling Depth(m)
500
580
680
800
Drilling Diameter(mm)
Φ140-350
Φ140-350
Φ140-400
Φ140-400
One-Time Advance Length(m)
6.6
6.6
6.6
6.6
Walking Speed(km/h)
2.5
2.5
2.5
2.5
Climbing Angles(°)
30
30
30
30
Engine & Power(kw)
118
132
153
194
Air Consumption(m3/min)
17-42
17-42
17-42
17-42
Drill Pipe Length(m)
1.5/2.0/3.0/6.0
1.5/2.0/3.0/6.0
1.5/2.0/3.0/6.0
1.5/2.0/3.0/6.0
Drill Pipe Diameter(mm)
Φ102 Φ108 Φ114
Φ102 Φ108 Φ114
Φ102 Φ108 Φ114
Φ102 Φ108 Φ114 Φ117
Rig Lifting Force(T)
26
28
30
36
Swing speed(rpm)
40-130
45-140
45-140
45-140
Swing torque(N.m)
7500-10000
8500-11000
8850-13150
9000-14000
Dimensions(mm)
6200*2200*2650
6200*2200*2650
6300*2300*2650
6300*2300*2650
Weight(kg)
11500
12000
13000
13000
